Horik LAN Cable UTP Category 6A Flat 50cm Purple LC05-504FB
JAN
4533115065047
ASIN
B08G81Z5B3
Manufacturer
Model Number
LC05-504FB
Color
Size
Description
Holic-LAN Cable-Category 6A-Flat-LC05-504FB
■Used to connect a computer's LAN port to network devices
LAN cables are essential for connecting PCs and game consoles to a network.
Additionally, wired LAN offers faster average communication speeds and greater stability compared to wireless LAN.
■CAT6A / Category 6A Compatible
CAT6A, compatible with 10GBASE-T, achieves a maximum transmission speed of 10Gbps.
It supports a transmission bandwidth of 500MHz, twice that of CAT6, supporting a fast and comfortable internet environment.
※Backward compatible with CAT6, CAT5e, and CAT5.
■Thin, Flat-Type Cable Design
With a slim 1.6mm profile, this flat-type cable is ideal for routing through tight spaces like door gaps, under carpets, or along walls.
■Plug cover prevents connector tab breakage
■UTP cable
■For indoor wiring
※Difference between 1000BASE-T and 1000BASE-TX
Gigabit LAN uses two communication standards: “1000BASE-T” (usable with CAT5e or higher) and “1000BASE-TX” (requires CAT6 or higher).
These two standards differ in how the four pairs of twisted wires inside the cable transmit data.
1000BASE-T transmits and receives (bidirectional communication) at 250Mbps per pair, resulting in 250Mbps × 4 = 1000Mbps.
▪️ Brand Name: HORIC
▪️ Connector Type: RJ-45 Connector
▪️ Wiring Method: Straight-Through Wiring
▪️ Cable Type: Twisted Pair (32AWG)
▪️ Maximum Data Rate: 10Gbps
▪️ Transmission Bandwidth: 500MHz
▪️ Supported Ethernet Standards: 10/100/1000/10Gbps
▪️Conductor: Twisted pair stranded wire (32AWG)
▪️Maximum Data Rate: 10Gbps
▪️Transmission Bandwidth: 500MHz
▪️Supported Ethernet Standards: 10G BASE-T, 1000BASE-TX (*), 1000BASE-T (*), 100BASE-TX, 10BASE-T
▪️Cable Type: UTP Cable
▪️Connector Size: W approx. 11.3 x H approx. 12.8 x D approx. 37.4 mm
▪️Cable Outer Diameter: W approx. 6.0 x H approx. 1.6 mm
▪️Cable Length: 50cm
▪️PE Bag Packaging
▪️Warranty Period: 1 year
4533115065047
Holic LAN Cable UTP Category 6A Flat 50cm Purple LC05-504FB
(text created at , 2025-05-11)
■Used to connect a computer's LAN port to network devices
LAN cables are essential for connecting PCs and game consoles to a network.
Additionally, wired LAN offers faster average communication speeds and greater stability compared to wireless LAN.
■CAT6A / Category 6A Compatible
CAT6A, compatible with 10GBASE-T, achieves a maximum transmission speed of 10Gbps.
It supports a transmission bandwidth of 500MHz, twice that of CAT6, supporting a fast and comfortable internet environment.
※Backward compatible with CAT6, CAT5e, and CAT5.
■Thin, Flat-Type Cable Design
With a slim 1.6mm profile, this flat-type cable is ideal for routing through tight spaces like door gaps, under carpets, or along walls.
■Plug cover prevents connector tab breakage
■UTP cable
■For indoor wiring
※Difference between 1000BASE-T and 1000BASE-TX
Gigabit LAN uses two communication standards: “1000BASE-T” (usable with CAT5e or higher) and “1000BASE-TX” (requires CAT6 or higher).
These two standards differ in how the four pairs of twisted wires inside the cable transmit data.
1000BASE-T transmits and receives (bidirectional communication) at 250Mbps per pair, resulting in 250Mbps × 4 = 1000Mbps.
▪️ Brand Name: HORIC
▪️ Connector Type: RJ-45 Connector
▪️ Wiring Method: Straight-Through Wiring
▪️ Cable Type: Twisted Pair (32AWG)
▪️ Maximum Data Rate: 10Gbps
▪️ Transmission Bandwidth: 500MHz
▪️ Supported Ethernet Standards: 10/100/1000/10Gbps
▪️Conductor: Twisted pair stranded wire (32AWG)
▪️Maximum Data Rate: 10Gbps
▪️Transmission Bandwidth: 500MHz
▪️Supported Ethernet Standards: 10G BASE-T, 1000BASE-TX (*), 1000BASE-T (*), 100BASE-TX, 10BASE-T
▪️Cable Type: UTP Cable
▪️Connector Size: W approx. 11.3 x H approx. 12.8 x D approx. 37.4 mm
▪️Cable Outer Diameter: W approx. 6.0 x H approx. 1.6 mm
▪️Cable Length: 50cm
▪️PE Bag Packaging
▪️Warranty Period: 1 year
4533115065047
Holic LAN Cable UTP Category 6A Flat 50cm Purple LC05-504FB
(text created at , 2025-05-11)
Package
Size (Approx.):
Size (Approx.):
85x14x89 mm
Package
Weight (Approx.):
Weight (Approx.):
20 g
393 JPY (Including Tax)
Stock :
5
Scheduled Shipping:
2025-12-11
Quantity :
Reference Price from Other Stores
