Horick Antenna Splitter Cable Integrated Type 1.5m/20cm White Screw-Type Connector AE-641WH
JAN
4533115066419
ASIN
B09MHFVQ1V
Maker
Model No.
AE-641WH
Color
Size
Description
Holic - Antenna Splitter - [4K8K Broadcast - 3224MHz - AE-641WH]
■ This is the one you need when you want to watch terrestrial digital broadcasts and BS/CS broadcasts separately. Efficiently splits terrestrial (UHF) and satellite (BS/110-degree CS) signals, allowing you to watch terrestrial digital, BS, and 110-degree CS broadcasts on a single TV.
■Compatible with New 4K8K Satellite Broadcasts Supports the latest 4K/8K broadcasts in addition to conventional terrestrial, BS, and 110-degree CS broadcasts.
■Integrated Cable Design The splitter unit and input/output cables are integrated, reducing connection loss compared to separate designs.
■BS Antenna Power Supply Capable
Brand Name: HORIC
▪️Input Frequency: 10 to 3224 MHz
▪️U/V Output Frequency: 10 to 770 MHz
▪️BS/CS Output Frequency: 1000 to 3224 MHz
▪️Cable Specification: S-4C-FB
▪️Connector Specification: F-type
▪️Connector Shape: L-shaped plug (gold-plated)
▪️Connector Size: W approx. 14.8 x H approx. 14.4 x D approx. 30.2 mm
▪️Impedance: 75Ω
▪️Cable Diameter: 6mm
▪️Cable Length: 1.5m
▪️Cable Specification: S-4C-FB
▪️Connector Specification: F-type
▪️Connector Shape: Screw-type (Gold-plated)
▪️Connector Size: W approx. 12.5 x H approx. 12.5 x D approx. 32.75 mm
▪️Impedance: 75Ω
▪️Cable Diameter: 6mm
▪️Cable Length: 20cm
Bag Packaging
▪️Warranty Period: 1 year
▪️Country of Origin: China
4533115066419
Horick Antenna Splitter Cable Integrated 1.5m/20cm White Screw-Type Connector AE-641WH
(text created at , 2025-06-30)
■ This is the one you need when you want to watch terrestrial digital broadcasts and BS/CS broadcasts separately. Efficiently splits terrestrial (UHF) and satellite (BS/110-degree CS) signals, allowing you to watch terrestrial digital, BS, and 110-degree CS broadcasts on a single TV.
■Compatible with New 4K8K Satellite Broadcasts Supports the latest 4K/8K broadcasts in addition to conventional terrestrial, BS, and 110-degree CS broadcasts.
■Integrated Cable Design The splitter unit and input/output cables are integrated, reducing connection loss compared to separate designs.
■BS Antenna Power Supply Capable
Brand Name: HORIC
▪️Input Frequency: 10 to 3224 MHz
▪️U/V Output Frequency: 10 to 770 MHz
▪️BS/CS Output Frequency: 1000 to 3224 MHz
▪️Cable Specification: S-4C-FB
▪️Connector Specification: F-type
▪️Connector Shape: L-shaped plug (gold-plated)
▪️Connector Size: W approx. 14.8 x H approx. 14.4 x D approx. 30.2 mm
▪️Impedance: 75Ω
▪️Cable Diameter: 6mm
▪️Cable Length: 1.5m
▪️Cable Specification: S-4C-FB
▪️Connector Specification: F-type
▪️Connector Shape: Screw-type (Gold-plated)
▪️Connector Size: W approx. 12.5 x H approx. 12.5 x D approx. 32.75 mm
▪️Impedance: 75Ω
▪️Cable Diameter: 6mm
▪️Cable Length: 20cm
Bag Packaging
▪️Warranty Period: 1 year
▪️Country of Origin: China
4533115066419
Horick Antenna Splitter Cable Integrated 1.5m/20cm White Screw-Type Connector AE-641WH
(text created at , 2025-06-30)
Package
Size (Approx.):
Size (Approx.):
154x25x211 mm
Package
Weight (Approx.):
Weight (Approx.):
130 g
