3.5x 45mm End Mill (AlCr coating/Carbide, 2 flutes)
JAN
4548745399981
ASIN
B004OSDOAW
Maker
Model No.
EA824RF-3.5
Color
Size
Description
ESCO - End Mill - AlCrCoat - TiAINCoat - TiNCoat・Co-HSS
Material: Carbide, GS Coating
Cutting Diameter: 3.5mm
Overall Length: 45mm
Cutting Length: 8.8mm
Shank Diameter: 6mm
Workpiece Materials: Low Carbon Steel, Mild Steel, Carbon Steel, Alloy Steel, Pre-hardened Steel, Quenched and Tempered Steel (HRC30/40), Hardened Steel (HRC40/55), Stainless Steel (SUS304), Heat-Resistant Alloy, Cast Iron
Suitable for wet machining of raw materials to high-speed dry machining of high-hardness materials.
The cutting edge is a gashland type.
Gashland Type:・Large tool angle provides high cutting edge strength.・Excellent chipping resistance.・A tapered section remains at the machined corner, making it unsuitable for precision finishing.
Brand Name: Esco
Material: Cemented Carbide
Material Composition: Cemented Carbide, GS Coating
Cutting Edge Diameter: 3.5mm
Overall Length: 45mm
Cutting Length: 8.8mm
Shank Diameter: 6mm
4548745399981
3.5x 45mm End Mill (AlCr coat/Cemented Carbide･2 flute)
(text created at , 2025-05-12)
Material: Carbide, GS Coating
Cutting Diameter: 3.5mm
Overall Length: 45mm
Cutting Length: 8.8mm
Shank Diameter: 6mm
Workpiece Materials: Low Carbon Steel, Mild Steel, Carbon Steel, Alloy Steel, Pre-hardened Steel, Quenched and Tempered Steel (HRC30/40), Hardened Steel (HRC40/55), Stainless Steel (SUS304), Heat-Resistant Alloy, Cast Iron
Suitable for wet machining of raw materials to high-speed dry machining of high-hardness materials.
The cutting edge is a gashland type.
Gashland Type:・Large tool angle provides high cutting edge strength.・Excellent chipping resistance.・A tapered section remains at the machined corner, making it unsuitable for precision finishing.
Brand Name: Esco
Material: Cemented Carbide
Material Composition: Cemented Carbide, GS Coating
Cutting Edge Diameter: 3.5mm
Overall Length: 45mm
Cutting Length: 8.8mm
Shank Diameter: 6mm
4548745399981
3.5x 45mm End Mill (AlCr coat/Cemented Carbide･2 flute)
(text created at , 2025-05-12)
Package
Size (Approx.):
Size (Approx.):
250x100x250 mm
Package
Weight (Approx.):
Weight (Approx.):
1000 g
5,570 JPY (Including Tax)
Stock :
1
Scheduled Shipping:
2026-04-01
Quantity :
Reference Price from Other Stores
