ESCO Inspector EA711-10A
JAN
4548745506532
ASIN
B01B8VQUR6
Maker
Model No.
EA711-10A
Color
Size
70 (W) × 30 (D) × 75 (H) mm (excluding protrusions)
Description
ESCO-EA711-10A-Phase Detector
Wide Type
IV・HIV Cable: 14/500mm², CV Cable: 3.5/500mm² Compatible
Non-contact Type. Detects phase over insulated wire
Electrostatic induction type
Operating voltage range: Three-phase AC 70/1000V
Phase detection indication:(Correct phase): Phase sequence 4-lamp sequential flashing (clockwise), intermittent buzzer sound (beep-beep), green arrow lit(Reverse phase): Phase sequence 4-lamp sequential flashing (counterclockwise), continuous buzzer tone (beep)
Operating frequency range: 45/66Hz
Live wire check, battery check, auto power-off function
Power source: 2 AA manganese batteries (included)
Brand name: Esco
Includes: Carrying case, strap, spiral tube, instruction manual, 2 AA manganese dry cell batteries\ Wide Type
IV/HIV Wire: 14/500mm², CV Wire: 3.5/500mm² Compatible
Non-contact type. Phase detection over insulated wires
Electrostatic induction type
Operating voltage range: Three-phase AC 70/1000V
4548745506532
B01B8VQUR6
Esco Phase Detector EA711-10A
(text created at , 2025-11-12)
Wide Type
IV・HIV Cable: 14/500mm², CV Cable: 3.5/500mm² Compatible
Non-contact Type. Detects phase over insulated wire
Electrostatic induction type
Operating voltage range: Three-phase AC 70/1000V
Phase detection indication:(Correct phase): Phase sequence 4-lamp sequential flashing (clockwise), intermittent buzzer sound (beep-beep), green arrow lit(Reverse phase): Phase sequence 4-lamp sequential flashing (counterclockwise), continuous buzzer tone (beep)
Operating frequency range: 45/66Hz
Live wire check, battery check, auto power-off function
Power source: 2 AA manganese batteries (included)
Brand name: Esco
Includes: Carrying case, strap, spiral tube, instruction manual, 2 AA manganese dry cell batteries\ Wide Type
IV/HIV Wire: 14/500mm², CV Wire: 3.5/500mm² Compatible
Non-contact type. Phase detection over insulated wires
Electrostatic induction type
Operating voltage range: Three-phase AC 70/1000V
4548745506532
B01B8VQUR6
Esco Phase Detector EA711-10A
(text created at , 2025-11-12)
Package
Size (Approx.):
Size (Approx.):
250x100x250 mm
Package
Weight (Approx.):
Weight (Approx.):
2000 g
35,265 JPY (Including Tax)
