“1” “Hose Coupling (Aluminum)”

4548745579413

B006Y4A3SK

EA462BF-8

A: 137, B: 61, C: 37, F: 19, G: 25, l: 27, h1: 60, H: 99

ESCO Coupling EA462B

Material: Aluminum die-cast (ADC12)
Working pressure: 1.76MPa (18kgf/cm2)
Working temperature: -30℃/70℃
Nominal diameter: 25 (1")
Suitable hose inner diameter: 25mm
Dimensions (mm): A:137, B: 61, C: 37, F: 19, G: 25, l: 27, h1: 60, H: 99
Weight: 0.18kg
This type is used with hose clamps or tightening on rubber hoses, PVC hoses, etc.
It can be easily connected and disconnected by operating the lever attached to the coupler.
Brand Name: Esco
Material: Aluminum Die Casting (ADC12)
Working Pressure: 1.76MPa (18kgf/cm²)
Working Temperature: -30℃/70℃
Nominal Diameter: 25 (1")
Suitable Hose Inner Diameter: 25mm
Size (mm): A:137, B:61, C:37, F:19, G:25, l:27, h1:60, H:99
It can be easily attached and detached by operating the lever on the coupler.
4548745579413
“1” “Hose Coupling (Aluminum)”
(text created at , 2025-05-10)

250x100x250 mm

2000 g
