ESCO Rc1/2 Electric Ball Valve (AC100V) EA470BG-4
JAN
4548745581492
ASIN
B006Y4A330
Maker
Model No.
EA470BG-4
Color
Size
d (bore diameter): 10, d1: Rc1/2, H: 109.5, H1: 33.5, L: 65, L1: 32.5, S1: 28, H2: 70, H3: 5, D: 60
Description
Brand Name: Esco
Material: Valve Body: Bronze (CAC406)
Material: Valve Body: Bronze (CAC406), Body Cap: C3771BE, Stem: High-Strength Brass (Cr Plated), Ball: K-Metal (Ni-Cr Plated), Ball Seat: PTFE, O-ring: FKM
Maximum Working Pressure: 0.98MPa
Working Fluid: Air, Water, Oil
Power Supply: AC100V (50/60Hz)
Rated Current: 90mA
Maximum Power Consumption: 9W
Maximum Output Torque: 1.9N·m
Rated Duty: Continuous
Insulation Class: Class E
Micro Switch Contact Rating: AC125V 2A (resistive load), AC250V 0.6A (resistive load)
4548745581492
B006Y4A330
ESCO Rc1/2 Electric Ball Valve (AC100V) EA470BG-4
(text created at , 2025-11-12)
Material: Valve Body: Bronze (CAC406)
Material: Valve Body: Bronze (CAC406), Body Cap: C3771BE, Stem: High-Strength Brass (Cr Plated), Ball: K-Metal (Ni-Cr Plated), Ball Seat: PTFE, O-ring: FKM
Maximum Working Pressure: 0.98MPa
Working Fluid: Air, Water, Oil
Power Supply: AC100V (50/60Hz)
Rated Current: 90mA
Maximum Power Consumption: 9W
Maximum Output Torque: 1.9N·m
Rated Duty: Continuous
Insulation Class: Class E
Micro Switch Contact Rating: AC125V 2A (resistive load), AC250V 0.6A (resistive load)
4548745581492
B006Y4A330
ESCO Rc1/2 Electric Ball Valve (AC100V) EA470BG-4
(text created at , 2025-11-12)
Package
Size (Approx.):
Size (Approx.):
250x100x250 mm
Package
Weight (Approx.):
Weight (Approx.):
2000 g
26,837 JPY (Including Tax)
Stock :
1
Scheduled Shipping:
2026-04-30
Quantity :
Reference Price from Other Stores
