ESCO Vinyl Wire for Electronic Equipment [KV] (Blue) 0.3mm² x 50m EA940AL-3BA
JAN
4548745590111
ASIN
B006Y4C4KK
Maker
Model No.
EA940AL-3BA
Color
Size
Description
Esco - Vinyl Wire for Electronic Equipment - KV
Excellent water resistance, flexibility, workability, and colorability.
Environmentally conscious, uses lead-free vinyl chloride resin.
Brand Name: Esco
Material: Conductor/Copper Sheath/Vinyl
Specifications: Stranded
Rated Temperature: 60°C・Rated Capacity: 300V
Specification: 1-core・Size: 0.3mm²
Number of Strands: 12・Strand Diameter: 0.18mm
Conductor Outer Diameter: 0.7mm・Insulation Thickness: 0.4mm
Outer Diameter: Approx. 1.5mm・Color: Blue
Length: 50m
Cord Part Number: EA940AL-3BA
4548745590111
ESCO Vinyl Wire for Electronic Equipment [KV] (Blue) 0.3mm² x 50m EA940AL-3BA
(text created at , 2025-05-12)
Excellent water resistance, flexibility, workability, and colorability.
Environmentally conscious, uses lead-free vinyl chloride resin.
Brand Name: Esco
Material: Conductor/Copper Sheath/Vinyl
Specifications: Stranded
Rated Temperature: 60°C・Rated Capacity: 300V
Specification: 1-core・Size: 0.3mm²
Number of Strands: 12・Strand Diameter: 0.18mm
Conductor Outer Diameter: 0.7mm・Insulation Thickness: 0.4mm
Outer Diameter: Approx. 1.5mm・Color: Blue
Length: 50m
Cord Part Number: EA940AL-3BA
4548745590111
ESCO Vinyl Wire for Electronic Equipment [KV] (Blue) 0.3mm² x 50m EA940AL-3BA
(text created at , 2025-05-12)
Package
Size (Approx.):
Size (Approx.):
400x400x400 mm
Package
Weight (Approx.):
Weight (Approx.):
1500 g
2,606 JPY (Including Tax)
Stock :
4
Scheduled Shipping:
2026-03-05
Quantity :
