ESCO Rc1/4 Needle Valve (Stainless Steel) EA470CM-2
JAN
4548745596359
ASIN
B006Y4AAF6
Maker
Model No.
EA470CM-2
Color
Size
d2: Rc1/4, H: 59, D1: 40, L: 40, I: 4, D2: 4, D3: 16, h: 13
Description
ESCO Needle Valve - Stainless Steel - EA470CM
Material: Body: SUS316, Stem: SUS630, Gasket: SUS316, Gasket Packing: PTFE, Panel Gasket: Non-asbestos Sheet, Set Screw: SUS304, Front Ferrule: SUS316, Back Ferrule: SUS316, Handle: ZDC\
Service Fluids: Air, Water, Oil, Gas, Chemicals\
Maximum Pressure: -20°C/ Ambient: 3.43MPa, Below 100°C: 2.94MPa, Below 150°C: 2.65MPa\
Panel tap provided at bottom of body for direct panel mounting\
For various equipment panel piping applications\
Mounting Screw (PT): 1/4”\
Size (mm): d2: Rc1/4, H:59, D1:40, L:40, I:4, D2:4, D3:16, h:13\
Weight: 0.161kg
Brand Name: Esco\
Material: Body: SUS316\
Material: Body: SUS316, Stem: SUS630, Gasket: SUS316, Gasket Packing: PTFE, Panel Gasket: Non-asbestos Sheet, Set Screw: SUS304, Front Ferrule: SUS316, Back Ferrule: SUS316, Handle: ZDC
Fluid Used: Air, Water, Oil, Gas, Chemicals
Maximum Pressure: -20℃/ Ambient: 3.43MPa, Below 100°C: 2.94MPa, Below 150°C: 2.65MPa
Panel tap provided at bottom of body for direct panel mounting
For various equipment panel piping
Mounting Screw (PT): 1/4"
Size (mm): d2: Rc1/4, H: 59, D1: 40, L:40, I:4, D2:4, D3:16, h:13
Weight:0.161kg
4548745596359\ nB006Y4AAF6
ESCO Rc1/4 Needle Valve (Stainless Steel) EA470CM-2
(text created at , 2025-11-12)
Material: Body: SUS316, Stem: SUS630, Gasket: SUS316, Gasket Packing: PTFE, Panel Gasket: Non-asbestos Sheet, Set Screw: SUS304, Front Ferrule: SUS316, Back Ferrule: SUS316, Handle: ZDC\
Service Fluids: Air, Water, Oil, Gas, Chemicals\
Maximum Pressure: -20°C/ Ambient: 3.43MPa, Below 100°C: 2.94MPa, Below 150°C: 2.65MPa\
Panel tap provided at bottom of body for direct panel mounting\
For various equipment panel piping applications\
Mounting Screw (PT): 1/4”\
Size (mm): d2: Rc1/4, H:59, D1:40, L:40, I:4, D2:4, D3:16, h:13\
Weight: 0.161kg
Brand Name: Esco\
Material: Body: SUS316\
Material: Body: SUS316, Stem: SUS630, Gasket: SUS316, Gasket Packing: PTFE, Panel Gasket: Non-asbestos Sheet, Set Screw: SUS304, Front Ferrule: SUS316, Back Ferrule: SUS316, Handle: ZDC
Fluid Used: Air, Water, Oil, Gas, Chemicals
Maximum Pressure: -20℃/ Ambient: 3.43MPa, Below 100°C: 2.94MPa, Below 150°C: 2.65MPa
Panel tap provided at bottom of body for direct panel mounting
For various equipment panel piping
Mounting Screw (PT): 1/4"
Size (mm): d2: Rc1/4, H: 59, D1: 40, L:40, I:4, D2:4, D3:16, h:13
Weight:0.161kg
4548745596359\ nB006Y4AAF6
ESCO Rc1/4 Needle Valve (Stainless Steel) EA470CM-2
(text created at , 2025-11-12)
Package
Size (Approx.):
Size (Approx.):
250x100x250 mm
Package
Weight (Approx.):
Weight (Approx.):
2000 g
21,627 JPY (Including Tax)
Stock :
3
Scheduled Shipping:
2026-02-04
Quantity :
Reference Price from Other Stores
