ESCO Rc1・1/4 Ball Valve (Stainless Steel) EA470AE-12
JAN
4548745597516
ASIN
B006Y49LLK
Maker
Model No.
EA470AE-12
Color
Size
Bore diameter: 20, Length: 78, Height: 54, Diameter: 100
Description
Material: Body: Stainless Steel (SCS13A), Stem: SUS304, Ball: SUS304, Ball Seat: Glass-Filled PTFE, Packing: Glass-Filled PTFE, Handle: SUS430 Maximum Pressure (Water/Oil/Gas): Ambient Temperature: 4.12MPa (42kgf/cm²) Thread Size (PT): 1-1/4" Operating Temperature Range: -30℃/230℃ Type: Floating Reduced Bore Connection Type: Screw-in: JIS B 0203 Size (mm): Bore Diameter: 20, L: 78, H: 54, D: 100 Weight: 0.683 kg
Brand Name: Esco
Material: Body: Stainless Steel (SCS13A)
Material: Body: Stainless Steel (SCS13A), Stem: SUS304, Ball: SUS304, Ball Seat: Glass-Filled PTFE, Packing: Glass-Filled PTFE, Handle: SUS430
Maximum Pressure (Water/Oil/Gas): Ambient: 4.12MPa (42kgf/cm2)
Thread Size (PT): 1-1/4"
Operating Temperature Range: -30℃/230℃
Type: Floating
Reduced Bore Type
Connection Type: Screw-in: JIS B 0203
Size (mm): Bore Diameter: 20, L: 78, H: 54, D: 100
Weight: 0.683 kg
4548745597516\ nB006Y49LLK
ESCO Rc1・1/4 Ball Valve (Stainless Steel) EA470AE-12
(text created at , 2025-11-12)
Brand Name: Esco
Material: Body: Stainless Steel (SCS13A)
Material: Body: Stainless Steel (SCS13A), Stem: SUS304, Ball: SUS304, Ball Seat: Glass-Filled PTFE, Packing: Glass-Filled PTFE, Handle: SUS430
Maximum Pressure (Water/Oil/Gas): Ambient: 4.12MPa (42kgf/cm2)
Thread Size (PT): 1-1/4"
Operating Temperature Range: -30℃/230℃
Type: Floating
Reduced Bore Type
Connection Type: Screw-in: JIS B 0203
Size (mm): Bore Diameter: 20, L: 78, H: 54, D: 100
Weight: 0.683 kg
4548745597516\ nB006Y49LLK
ESCO Rc1・1/4 Ball Valve (Stainless Steel) EA470AE-12
(text created at , 2025-11-12)
Package
Size (Approx.):
Size (Approx.):
250x100x250 mm
Package
Weight (Approx.):
Weight (Approx.):
2000 g
13,662 JPY (Including Tax)
Stock :
1
Scheduled Shipping:
2026-06-26
Quantity :
Reference Price from Other Stores
