ESCO 1-1/2 Swing Check Valve EA465AA-14
JAN
4548745612578
ASIN
B006Y4ASQW
Maker
Model No.
EA465AA-14
Color
Size
L: 120, H: 72
Description
Material: Body: SCS13A, Cap: SCS13A/SUS304, Disc: SCS13A, Hinge Pin: SUS304, Plug: SUS304, Plug Gasket: Non-asbestos sheet gasket Maximum Pressure: Clean water (120°C or below): 1.4MPa, Steam/Air/Non-flammable Gas/Oil (150°C or below): 1.1MPa, Steam/Air/Non-flammable Gas/Oil (180°C or below): 1.0MPa Class: 10K Operation Method: Check Connection Type: Screw-in: JIS B 0203 Nominal Size (Size): 40 (1-1/2") Size (mm): L: 120, H: 72 Weight: 1.82 kg
Brand Name: Esco
Material: Body: SCS13A
Material: Body: SCS13A, Cap: SCS13A/SUS304, Disc: SCS13A, Hinge Pin: SUS304, Plug: SUS304, Plug Gasket: Non-asbestos Sheet Gasket
Maximum Pressure: Clean Water (120°C or below): 1.4MPa, Steam/Air/Non-flammable Gas/Oil (150°C or below): 1.1MPa, Steam, Air, Non-Flammable Gas, Oil (180°C or below): 1.0MPa
Class: 10K
Operation Method: Check
Connection Type: Screw-in: JIS B 0203
Nominal Size: 40 (1-1/2")
Size (mm): L: 120, H: 72
Weight: 1.82 kg
4548745612578
B006Y4ASQW
ESCO 1-1/2 Swing Check Valve EA465AA-14
(text created at , 2025-11-12)
Brand Name: Esco
Material: Body: SCS13A
Material: Body: SCS13A, Cap: SCS13A/SUS304, Disc: SCS13A, Hinge Pin: SUS304, Plug: SUS304, Plug Gasket: Non-asbestos Sheet Gasket
Maximum Pressure: Clean Water (120°C or below): 1.4MPa, Steam/Air/Non-flammable Gas/Oil (150°C or below): 1.1MPa, Steam, Air, Non-Flammable Gas, Oil (180°C or below): 1.0MPa
Class: 10K
Operation Method: Check
Connection Type: Screw-in: JIS B 0203
Nominal Size: 40 (1-1/2")
Size (mm): L: 120, H: 72
Weight: 1.82 kg
4548745612578
B006Y4ASQW
ESCO 1-1/2 Swing Check Valve EA465AA-14
(text created at , 2025-11-12)
Package
Size (Approx.):
Size (Approx.):
53x52x86 mm
Package
Weight (Approx.):
Weight (Approx.):
106 g
33,777 JPY (Including Tax)
Stock :
1
Scheduled Shipping:
2026-06-29
Quantity :
