ESCO R1/8" x 6mm Needle Valve (Flare) EA426CF-106
JAN
4548745732092
ASIN
B00AXUK9SK
Maker
Model No.
EA426CF-106
Color
Size
Description
ESCO Needle Valve - Flare
Material: Brass (Chrome-plated finish)
Pressure: 0.98MPa (10kgf/cm²) or less
Temperature: -10/80°C (excluding freezing locations)
Fluid: Air, Water, Oil
Mounting Thread (A): R(PT) 1/8"\ Copper Tube OD: 6mm
Weight: 85g
Flare type for copper tubing
Straight type
Applications: Pneumatic equipment such as compressors, small pumps and accessories, marine and agricultural equipment, hydraulic equipment for copper tubing piping, instrumentation equipment, machine tools and equipment, other industrial machinery and apparatus.
Features a tapered (PT) external thread on the primary side and a secondary side that clamps copper tubing with a flare nut.
Installation requires flaring the end face of the copper tube after threading the nut.
Brand Name: Esco
Temperature: -10/80°C (Excluding freezing locations)
Mounting Thread (A): R(PT) 1/8"
Copper Tube OD: 6mm
4548745732092
Esco R1/8" x 6mm Needle Valve (Flare) EA426CF-106
(text created at , 2025-05-13)
Material: Brass (Chrome-plated finish)
Pressure: 0.98MPa (10kgf/cm²) or less
Temperature: -10/80°C (excluding freezing locations)
Fluid: Air, Water, Oil
Mounting Thread (A): R(PT) 1/8"\ Copper Tube OD: 6mm
Weight: 85g
Flare type for copper tubing
Straight type
Applications: Pneumatic equipment such as compressors, small pumps and accessories, marine and agricultural equipment, hydraulic equipment for copper tubing piping, instrumentation equipment, machine tools and equipment, other industrial machinery and apparatus.
Features a tapered (PT) external thread on the primary side and a secondary side that clamps copper tubing with a flare nut.
Installation requires flaring the end face of the copper tube after threading the nut.
Brand Name: Esco
Temperature: -10/80°C (Excluding freezing locations)
Mounting Thread (A): R(PT) 1/8"
Copper Tube OD: 6mm
4548745732092
Esco R1/8" x 6mm Needle Valve (Flare) EA426CF-106
(text created at , 2025-05-13)
Package
Size (Approx.):
Size (Approx.):
250x100x250 mm
Package
Weight (Approx.):
Weight (Approx.):
2000 g
1,467 JPY (Including Tax)
