ELECOM LAN Cable CAT6A Compliant Long Length Connectorless RoHS Directive Compliant Solid Wire Relax 300m Blue LD-GPAL/BU300RS

4549550171601

B088P92H56

LD-GPAL/BU300RS

ELECOM LAN Cable RoHS Directive Compliant LD-GPAL-BU300RS
\


■Specifications: Cat6A compliant (supports 10GBASE-T/1000BASE-TX/1000BASE-T/100BASE-TX/10BASE-T)\


■Transmission Speed: 10Gbps\


■Transmission Bandwidth: Up to 500MHz\


■Cable Length: Approx. 300m\


■Cable Diameter: Approx. 6.2mm\


■Number of Cores: 8\


■Cross-shaped Spacer: Yes\


■Outer Sheath Material: PVC\


■Length Markings: Yes\


■Color: Blue\


■Conductor Configuration: Solid Wire (AWG23)\


■Conductor Diameter: Approx. 0.58mm (AWG23)\


■Molded Connector: No\


■Slim Connector: ×\


■Connector with Clip-Break Prevention Cover: ×\


■Cable Retraction Function: ×\


■Package Type: Cardboard Box (Drum Wound)\


■Environmental Compliance: EU RoHS Directive Compliant (10 Substances)\


■PoE: ○ (PoE/PoE+) ※Up to 100m\


■Compatible Connectors: LD-6RJ45T10, LD-6RJ45T100\
Supports high-frequency bandwidth up to 500MHz (twice that of Cat6), offers strong resistance to noise interference, and enables a high-speed, stable network environment.\


■Single-wire design minimizes attenuation over long distances; connector-free cable-only type.\


■Environmentally friendly product compliant with the EU's “RoHS Directive (Restriction of the Use of Certain Hazardous Substances in Electrical and Electronic Equipment)” (10 substances).\


■Cross-shaped dielectric inserts within the cable prevent signal interference, ensuring stable data transfer.\


■Includes length markings to indicate remaining usable length. *Length marks are a rough guide to remaining length.\


■Compatible with PLC, ADSL lines, CATV lines, optical communication lines, and ISDN lines.\


■Boxed rewind type, convenient for creating LAN cables of the required length. Resists tangling and is suitable for dispensing small amounts at a time.\


■Features soft-material clips to prevent connection failures due to clip breakage.\


■The vivid color of the core wires makes identification easy and facilitates processing.\


■Compatible connectors are LD-6RJ45T10 (10-pack) and LD-6RJ45T100 (100-pack).\


■This product's packaging consists solely of paper, cardboard, and polyethylene bags.\
ELECOM General Information Center\
TEL. 0570-084-465\
FAX. 0570-050-012\
Hours: 10:00 AM to 7:00 PM, Open Year-Round\
Brand Name: ELECOM\
Unit Only\
This is a long-length type Cat6A LAN cable for DIY use, compatible with 10 Gigabit Ethernet and guaranteed to support a 500MHz frequency bandwidth. You can make your own LAN cable using the dedicated stripping tool and connectors. It uses solid-core cable for low attenuation even over long distances. ※Connectors are not included.
Supports high-frequency bands up to 500MHz—twice that of Cat6—offering strong resistance to noise interference for a fast, stable network environment.
Single-wire construction minimizes attenuation over long distances; this is a cable-only type without connectors.
Environmentally friendly product compliant with the EU's RoHS Directive (Restriction of Hazardous Substances in Electrical and Electronic Equipment) covering 10 substances.
Cross-shaped filler material inside the cable

337x270x344 mm

15820 g
