ELECOM USB Audio Conversion Adapter φ3.5mm USB to Stereo Mini Jack 3-pin/4-pin Compatible Noise Reduction Direct Plug-in Type Black USB-AADC01BK
JAN
4549550210416
ASIN
B097NYHCDR
Maker
Model No.
USB-AADC01BK
Color
Size
Description
ELECOM USB Audio Conversion Adapter φ3-5mm Stereo Mini Jack to USB-A AADC01BK
■ Compatible Devices: Windows PCs, Macs, and game consoles (PS5, PS4, PS3) equipped with a USB 2.0 Type-A port
■ Connector Configuration: USB 2.0 Standard-A Male - φ3.5mm Stereo Mini Jack ×1 (Audio Output) + φ3.5mm Mini Jack ×1 (Microphone Input)
■ Audio Output: φ3.5mm Stereo Mini Jack (3-pin and 4-pin compatible)
■ Microphone Input: φ3.5mm Mini Jack (3-pin)
■ External Dimensions (W×H×D): Main Case Approx. 25mm×Approx. 35mm×Approx. 10mm
■ Sampling Frequency: 44.1kHz/48kHz
■ Frequency Response: 20Hz~20kHz
■ Color: Black
■ Packaging: Blister pack + paper backing
■ Features two connectors: a φ3.5mm stereo mini jack (compatible with both 3-pin and 4-pin plugs) for audio output and a 3-pin φ3.5mm mini jack for microphone input.
■ Compatible with traditional PC headsets featuring separate headphone and microphone jacks, as well as smartphone 4-pole φ3.5mm mini plugs (CTIA standard) with microphone earbuds.
■ Can be used with PC headsets and smartphone microphone earbuds even on PCs without a dedicated microphone jack.
■ Connect to laptops, desktop PCs, or game consoles with USB ports supporting audio output to use headphones, headsets, speakers, microphones, and more.
■ Tuned to clearly convey mid-range frequencies, it enables transmission of clear voice to call recipients while suppressing environmental noise.
■ No sound card or drivers required—simply plug into a USB port for easy connection.
■ Connecting via USB enables digital transmission, minimizing interference from internal computer noise.
※ Depending on the placement of USB ports on your device, this product may interfere with adjacent ports.
■ This product is an active type with an IC chip.
ELECOM General Information Center
TEL. 0570-084-465
FAX. 0570-050-012
Hours: 10:00 AM to 7:00 PM, Open Year-Round
Brand Name: ELECOM
Equipped with two connectors: a φ3.5mm stereo mini jack (compatible with both 3-pin and 4-pin) for audio output, and a 3-pin φ3.5mm mini jack for microphone input.
In addition to conventional PC headsets with separate headphone and microphone jacks, it also supports smartphone 4-pin φ3.5mm mini plugs (CTIA standard) with microphone-equipped earphones.
Even on PCs without a dedicated microphone port, you can use PC headsets and smartphone earphones with microphones.
Connect to laptops, desktop PCs, or game consoles with USB ports supporting audio output to use headphones, headsets, speakers, microphones, and more.
Tuned to clearly convey mid-range frequencies, it enables clear voice transmission to call recipients while suppressing ambient noise.
4549550210416
ELECOM USB Audio Conversion Adapter φ3.5mm USB to Stereo Mini Jack 3-pin/4-pin Compatible Noise Reduction Direct Plug-in Type Black USB-AADC01BK
(text created at , 2025-05-11)
■ Compatible Devices: Windows PCs, Macs, and game consoles (PS5, PS4, PS3) equipped with a USB 2.0 Type-A port
■ Connector Configuration: USB 2.0 Standard-A Male - φ3.5mm Stereo Mini Jack ×1 (Audio Output) + φ3.5mm Mini Jack ×1 (Microphone Input)
■ Audio Output: φ3.5mm Stereo Mini Jack (3-pin and 4-pin compatible)
■ Microphone Input: φ3.5mm Mini Jack (3-pin)
■ External Dimensions (W×H×D): Main Case Approx. 25mm×Approx. 35mm×Approx. 10mm
■ Sampling Frequency: 44.1kHz/48kHz
■ Frequency Response: 20Hz~20kHz
■ Color: Black
■ Packaging: Blister pack + paper backing
■ Features two connectors: a φ3.5mm stereo mini jack (compatible with both 3-pin and 4-pin plugs) for audio output and a 3-pin φ3.5mm mini jack for microphone input.
■ Compatible with traditional PC headsets featuring separate headphone and microphone jacks, as well as smartphone 4-pole φ3.5mm mini plugs (CTIA standard) with microphone earbuds.
■ Can be used with PC headsets and smartphone microphone earbuds even on PCs without a dedicated microphone jack.
■ Connect to laptops, desktop PCs, or game consoles with USB ports supporting audio output to use headphones, headsets, speakers, microphones, and more.
■ Tuned to clearly convey mid-range frequencies, it enables transmission of clear voice to call recipients while suppressing environmental noise.
■ No sound card or drivers required—simply plug into a USB port for easy connection.
■ Connecting via USB enables digital transmission, minimizing interference from internal computer noise.
※ Depending on the placement of USB ports on your device, this product may interfere with adjacent ports.
■ This product is an active type with an IC chip.
ELECOM General Information Center
TEL. 0570-084-465
FAX. 0570-050-012
Hours: 10:00 AM to 7:00 PM, Open Year-Round
Brand Name: ELECOM
Equipped with two connectors: a φ3.5mm stereo mini jack (compatible with both 3-pin and 4-pin) for audio output, and a 3-pin φ3.5mm mini jack for microphone input.
In addition to conventional PC headsets with separate headphone and microphone jacks, it also supports smartphone 4-pin φ3.5mm mini plugs (CTIA standard) with microphone-equipped earphones.
Even on PCs without a dedicated microphone port, you can use PC headsets and smartphone earphones with microphones.
Connect to laptops, desktop PCs, or game consoles with USB ports supporting audio output to use headphones, headsets, speakers, microphones, and more.
Tuned to clearly convey mid-range frequencies, it enables clear voice transmission to call recipients while suppressing ambient noise.
4549550210416
ELECOM USB Audio Conversion Adapter φ3.5mm USB to Stereo Mini Jack 3-pin/4-pin Compatible Noise Reduction Direct Plug-in Type Black USB-AADC01BK
(text created at , 2025-05-11)
Package
Size (Approx.):
Size (Approx.):
94x10x198 mm
Package
Weight (Approx.):
Weight (Approx.):
20 g
2,106 JPY (Including Tax)
Stock :
5
Scheduled Shipping:
2026-05-18
Quantity :
Reference Price from Other Stores
