ELECOM USB-C Adapter Type-C to DisplayPort (2 Ports) 8K (7680×4320px)/30Hz Multi-Display Mirroring 0.12m Cable Black AD-CDP2BK2

4549550334495

B0DFWBZ7DJ

AD-CDP2BK2

ELECOM-DisplayPort-7680×4320px-Multi-Display-AD-CDP2BK2
\


■Connector Type 1: USB Type-C Plug\


■Connector Type 2: DisplayPort Ports ×2\


■Compatible Devices: USB Type-C Plug Side: PCs equipped with USB Type-C ports supporting DisplayPort Alt Mode, etc.\


■Compatible Devices: DisplayPort Port Side: DisplayPort cables/displays, projectors, etc.\


■Supported Resolution: Single Display Connection: Max 8K (7680×4320px)/30Hz, Dual Display Connection: Max 4K (3840×2160px)/60Hz\


■Cable Type: Normal Type\


■Cable Length: Approx. 12cm (excluding connectors)\


■Dimensions: Width approx. 55mm × Thickness approx. 12mm × Height approx. 50mm (adapter section)\


■Color: Black\


■Package Type: Paper Box\


■Environmental Considerations: Complies with EU RoHS Directive (10 substances), THINK ECOLOGY Mark\


■This conversion adapter outputs video to displays equipped with DisplayPort connectors. It can output video signals from devices like USB Type-C port-equipped computers to up to two displays with DisplayPort connectors, supporting both screen mirroring and extended display modes. *Cannot convert from DisplayPort to USB Type-C plug. *Supports audio output. *If video does not display correctly, try turning the connected display's power ON/OFF or unplugging and replugging each connection. *May not function properly depending on the environment or device. *Operation is not guaranteed with all devices. *When using this product for video output, ensure the output device supports DisplayPort Alt Mode. ※Compatible devices (such as DisplayPort cables) are not included. Please purchase or prepare them separately.\


■Supports screen extension, which displays multiple connected displays as a single screen, and screen mirroring, which displays the same screen as the output device. ※Video output is possible from the output device (such as a PC) to up to two displays. In this case, a maximum of three screens can be displayed. *When connecting one display: Supports up to 8K (7680×4320px)/30Hz. When connecting two displays: Supports up to 4K (3840×2160px)/60Hz per display. * Connected devices must support screen mirroring or extended display. * Some smartphone/tablet models may not support extended display.\


■ Supports resolutions up to 8K (7680×4320px)/30Hz.\


■ Supports HDCP 2.2/1.4 copyright protection technology.\


■ This product is an active type with an integrated circuit (IC).\


■The adapter's interior features a metal shell structure with high shielding effectiveness, minimizing susceptibility to external noise.\


■Uses triple-shielded cables to reduce interference from external noise.\


■Features gold-plated pins resistant to corrosion and signal degradation.\


■No drivers required; simply connect devices to use. ※USB Type-C and USB-C are trademarks of USB Implementers Forum.

83x21x173 mm

70 g
