16-pole [50V/3A] Screwless Terminal Block (PCB Mount / White)
JAN
4550061097823
ASIN
B0BWR3W9LG
Maker
Model No.
EA940DM-216
Color
Size
15.6 × 13.5 mm
Description
Brand Name: Esco
Poles: 16-pole
Size (Width): 42.14mm
Rated: 50V-3A
Acceptable Wire: Solid Wire / φ0.32–0.65mm Stranded Wire / 0.08–0.32mm² (Single Wire Diameter φ0.12mm or larger)
Size (Depth × Height): 15.65 × 13.5mm
Material: Body / Nylon 66 (UL94V-0) Button / Modified PPE (UL94V-0)
Insulation resistance: DC500V, 50MΩ or higher
Withstand voltage: AC1500V (1 minute)
Certifications: UL standard (Field Wiring compliant)・CSA standard・TUV standard (Compliant with IEC60947-7-1)
Standard wire stripping length: 9 to 10mm
4550061097823
16-pole [50V/3A] Screwless Terminal Block (PCB Mount / White)
(text created at , 2025-05-12)
Poles: 16-pole
Size (Width): 42.14mm
Rated: 50V-3A
Acceptable Wire: Solid Wire / φ0.32–0.65mm Stranded Wire / 0.08–0.32mm² (Single Wire Diameter φ0.12mm or larger)
Size (Depth × Height): 15.65 × 13.5mm
Material: Body / Nylon 66 (UL94V-0) Button / Modified PPE (UL94V-0)
Insulation resistance: DC500V, 50MΩ or higher
Withstand voltage: AC1500V (1 minute)
Certifications: UL standard (Field Wiring compliant)・CSA standard・TUV standard (Compliant with IEC60947-7-1)
Standard wire stripping length: 9 to 10mm
4550061097823
16-pole [50V/3A] Screwless Terminal Block (PCB Mount / White)
(text created at , 2025-05-12)
Package
Size (Approx.):
Size (Approx.):
- mm
Package
Weight (Approx.):
Weight (Approx.):
- g
1,172 JPY (Including Tax)
Stock :
25
Scheduled Shipping:
2026-07-14
Quantity :
