OSG Hand Tap Long/HSSE M8×1.25/1.5P/100mm EA829HV-242

4550061286920

B0CK4L39C2

EA829HV-242

OSG-Hand Tap-HSSE-M8×1.25-EA829HV

▪️Manufacturer: OSG
▪️Model: EX-LT STD
▪️Nominal Size: M8×1.25
▪️Overall Length (mm): 100
▪️Thread Pitch: 1.5P
▪️Material: HSSE (High-Vanadium High-Speed Steel)
▪️Thread Length (mm): 22
▪️Shank Diameter (mm): 6.2
▪️Workpiece Materials: Medium Carbon Steel, Cast Steel, Ductile Cast Iron, Brass, Cast Brass, Bronze, Rolled Aluminum, Cast Aluminum Alloy, Cast Magnesium Alloy, Cast Zinc Alloy
▪️Flute Count: 4
▪️Weight (g): 26
▪️Length (mm): 8
▪️Width (mm): 5
▪️For blind holes and through holes. Suitable for materials producing fine chips and high-hardness materials.
※※For business use only※※
Brand Name: OSG
Manufacturer: OSG
Model Number: EX-LT STD
Nominal Size: M8×1.25
Overall Length (mm): 100
Thread Pitch: 1.5P
Material: HSSE (High-Vanadium High-Speed Steel)
Thread Length (mm): 22
Shank Diameter (mm): 6.2
Materials: Medium carbon steel, cast steel, ductile cast iron, brass, brass castings, bronze, rolled aluminum, aluminum alloy castings, magnesium alloy castings, zinc alloy castings
Flute Count: 4
4550061286920
OSG Hand Tap Long/HSSE M8×1.25/1.5P/100mm EA829HV-242
