Sato Keiryoki Seisakujo Temperature Data Logger (Separate Type + Separate Type) EA742GB-2A

4550061454015

B08XYTDBSS

EA742GB-2A

Main unit: 114 (W) × 35 (D) × 80 (H) mm Sensor: φ3.3 × 13 (H) mm

ESCO-Separate Type-Temperature Data Logger-EA742GB-2A
Features\
・Freely select the data storage method from four memory modes. 1. One-Time Mode: Continues storing data until memory is full. Automatically stops recording when the data count reaches 16,000. 2. Endless Mode (Overwrite Mode): Overwrites data from the beginning when memory is full. Ideal for collecting data over a predetermined period. 3. Data Count Specified Mode: Allows presetting the number of data points to store between 1 and 16,000. Optimal when only specific data is needed. 4. Page Mode (Memory Partition Mode): Divides memory into 4 sections (4 pages). Each section sequentially stores data from different locations or times, enabling one unit to function as multiple units. Each page can store 4,000 data points.\
\
Specifications\
・Manufacturer: Sato Measuring Instruments Co.\
・Model: SK-L751 (Sensor included)\
・Measurement Range: -40.0 to 80.0°C\
・Resolution: 0.1°C\
・Storage Capacity: 16,000 data points per channel\
・Power Supply: 2 AA batteries (included)\
・Dimensions: Main Unit/114(W)×35(D)×80(H)mm Sensor/φ3.3×13(H)mm\
・Display Accuracy: ±0.2℃ (0～40℃) ±0.3℃ (outside this range)\
・Measurement Accuracy: Detached sensor: ±0.5°C\
・Display sampling: Approx. 1 second\
・Functions: Temperature/humidity alarm (ALM), memory mode, status display (REC/RES), memory capacity (bar), SD memory, low battery indicator, key lock indicator, various error messages, setting value display during configuration\
・Number of measurement channels: 2 temperature channels\
・External memory: microSD/SDHC up to 32GB ※Please use commercially available memory cards that are pre-formatted. *This device supports the FAT32 format only. NTFS format cannot be used with this device.\
・Recording Interval: 1 second, 2 seconds, 5 seconds, 10 seconds, 15 seconds, 30 seconds, 1 minute, 2 minutes, 5 minutes, 10 minutes, 15 minutes, 30 minutes, 60 minutes, 90 minutes (14 options)\
・Operating Environment: -10 to 60°C (14 to 140°F), 85% rh or less (no condensation)\
・Storage Environment: -10 to 60°C (14 to 140°F), 85% rh or less (no condensation)\
・Battery Life: Approx. 500 hours in measurement mode\
・Weight: Main unit/approx. 232g (including battery) Sensor/approx. 23g\
・Accessories: AA batteries × 2, Communication cable × 1, Instruction manual, Quick manual, Analysis software CD-ROM\
・Temperature sensor: Thermistor\
・Sensor material: Sensor section/SUS304, Connector section/PVC resin, Cord/PVC resin\
・Cord length: 1.6m (Sensor)\
・Compatible interfaces: Windows 10, 8.1, 8 (All 64-bit/32-bit Japanese versions) *All must have the latest service pack installed\
・Dustproof/Waterproof: Complies with JIS C 0920 IP65
Brand Name: Esco
Material: Sensor Section/SUS304 Connector Section/PVC Resin Cord/PVC Resin
Quantity: 1 set
Model Number: EA742GB-2A
Size: Main Unit/114(W)×35(D)×80(H)mm Sensor/φ3.3×13(H)mm
Sensor Material: Sensor Section/SUS304 Connector Section/PVC Resin Cord/PVC Resin
4550061454015
B08XYTDBSS
Sato Keiryoki Seisakusho (Sato Keiryoki)

151x100x162 mm

470 g
