ESCO Leak Clamp Tester (Digital) EA708LB-3A
JAN
4550061457429
ASIN
B08XYR6RZN
Maker
Model No.
EA708LB-3A
Color
Size
37 (W) × 27 (D) × 160 (H) mm
Description
▪️Manufacturer…HIOKI\
▪️Model Number…CM4001\
▪️AC Current…60.00mA/600.0mA/6.000A/60.00A/600.0A, 5 ranges, True RMS rectified basic accuracy: 45-66Hz: ±1.5% rdg ±5 dgt (60.00mA~6.000A), ±2.5% rdg ±5 dgt (60.00A~600.0A) Accuracy range: 0.60mA~600.0A\
▪️Frequency...40.0Hz~999.9Hz\
▪️Clamp Inner Diameter...φ24mm\
▪️Crest Factor...4.5 for counts ≤4000; 3 for counts >4000 and ≤6000\
▪️Filter Function...Cutoff frequency 180Hz ±30Hz (-3 dB) when ON\
▪️Functions…Comparator function, max/min/average value record function, backlight, data hold, auto power off, inrush current measurement\
▪️Display…Display update rate: 5 times/second\
▪️Power supply…1 AAA battery (included)\
▪️Continuous operating time…32 hours\
▪️Size…37(W)×27(D)×160(H)mm\
▪️Weight…115g\
▪️Accessories…Carrying case, strap, instruction manual, safety precautions\
▪️Accuracy guaranteed from 0.60mA to 600.0A. One unit handles various field applications.\
▪️Reduce troubleshooting time with the comparator function. Set a threshold and receive audible and visual alerts for comparison results. Quickly pinpoint leakage locations.\
▪️Effortlessly clamps thick wires with narrow spacing or double wiring. Various convenient functions support troubleshooting and diagnosis.\
▪️Easy-to-use jaws for effortless operation (up to φ24 mm diameter)\
▪️Measures from leakage current to load current\
▪️For leakage troubleshooting and insulation management\
▪️CAT III 300V\
▪️True RMS measurement capability
Brand Name: Esco
4550061457429
B08XYR6RZN
Esco Leak Clamp Tester (Digital) EA708LB-3A
(text created at , 2025-11-12)
▪️Model Number…CM4001\
▪️AC Current…60.00mA/600.0mA/6.000A/60.00A/600.0A, 5 ranges, True RMS rectified basic accuracy: 45-66Hz: ±1.5% rdg ±5 dgt (60.00mA~6.000A), ±2.5% rdg ±5 dgt (60.00A~600.0A) Accuracy range: 0.60mA~600.0A\
▪️Frequency...40.0Hz~999.9Hz\
▪️Clamp Inner Diameter...φ24mm\
▪️Crest Factor...4.5 for counts ≤4000; 3 for counts >4000 and ≤6000\
▪️Filter Function...Cutoff frequency 180Hz ±30Hz (-3 dB) when ON\
▪️Functions…Comparator function, max/min/average value record function, backlight, data hold, auto power off, inrush current measurement\
▪️Display…Display update rate: 5 times/second\
▪️Power supply…1 AAA battery (included)\
▪️Continuous operating time…32 hours\
▪️Size…37(W)×27(D)×160(H)mm\
▪️Weight…115g\
▪️Accessories…Carrying case, strap, instruction manual, safety precautions\
▪️Accuracy guaranteed from 0.60mA to 600.0A. One unit handles various field applications.\
▪️Reduce troubleshooting time with the comparator function. Set a threshold and receive audible and visual alerts for comparison results. Quickly pinpoint leakage locations.\
▪️Effortlessly clamps thick wires with narrow spacing or double wiring. Various convenient functions support troubleshooting and diagnosis.\
▪️Easy-to-use jaws for effortless operation (up to φ24 mm diameter)\
▪️Measures from leakage current to load current\
▪️For leakage troubleshooting and insulation management\
▪️CAT III 300V\
▪️True RMS measurement capability
Brand Name: Esco
4550061457429
B08XYR6RZN
Esco Leak Clamp Tester (Digital) EA708LB-3A
(text created at , 2025-11-12)
Package
Size (Approx.):
Size (Approx.):
- mm
Package
Weight (Approx.):
Weight (Approx.):
- g
56,229 JPY (Including Tax)
Stock :
2
Scheduled Shipping:
2026-02-12
Quantity :
Reference Price from Other Stores
