ESCO AC200V・Rc1/4" 2-Way Solenoid Valve Pilot Operated EA153HB-12
JAN
4550061506837
ASIN
B092QTWVCW
Maker
Model No.
EA153HB-12
Color
Size
Description
ESCO-AC200V･Rc1-2-Way Solenoid Valve-EA153HB-12
▪️Rated Voltage…AC200V
▪️Operating Fluid…Air・Water・Kerosene・Oil (up to 60℃)
▪️Maximum Operating Pressure…2MPa
▪️Ambient Temperature…-20~60℃
▪️Fluid Temperature…-10~60℃ (No freezing)
▪️Pressure Resistance…8MPa (Water pressure)
▪️Heat Resistance Class…Class 130 (B)
▪️Valve Structure…Pilot-operated poppet structure, Diaphragm driven
▪️Materials…Body: Bronze Seal: Nitrile rubber
▪️Connection Size…Rc1/4
▪️Orifice Diameter (Φmm)…10
▪️Weight (g)…400
▪️Switching Direction…2-way
▪️AD11 Series
Brand Name: Esco
Rated Voltage…AC200V
Operating Fluid…Air, Water, Kerosene, Oil (up to 60°C)
Maximum Operating Pressure…2 MPa
Ambient Temperature…-20 to 60℃
Fluid Temperature…-10 to 60℃ (No freezing)
4550061506837
ESCO AC200V・Rc1/4" 2-Way Solenoid Valve Pilot Operated EA153HB-12
(text created at , 2025-07-01)
▪️Rated Voltage…AC200V
▪️Operating Fluid…Air・Water・Kerosene・Oil (up to 60℃)
▪️Maximum Operating Pressure…2MPa
▪️Ambient Temperature…-20~60℃
▪️Fluid Temperature…-10~60℃ (No freezing)
▪️Pressure Resistance…8MPa (Water pressure)
▪️Heat Resistance Class…Class 130 (B)
▪️Valve Structure…Pilot-operated poppet structure, Diaphragm driven
▪️Materials…Body: Bronze Seal: Nitrile rubber
▪️Connection Size…Rc1/4
▪️Orifice Diameter (Φmm)…10
▪️Weight (g)…400
▪️Switching Direction…2-way
▪️AD11 Series
Brand Name: Esco
Rated Voltage…AC200V
Operating Fluid…Air, Water, Kerosene, Oil (up to 60°C)
Maximum Operating Pressure…2 MPa
Ambient Temperature…-20 to 60℃
Fluid Temperature…-10 to 60℃ (No freezing)
4550061506837
ESCO AC200V・Rc1/4" 2-Way Solenoid Valve Pilot Operated EA153HB-12
(text created at , 2025-07-01)
Package
Size (Approx.):
Size (Approx.):
- mm
Package
Weight (Approx.):
Weight (Approx.):
- g
9,706 JPY (Including Tax)
