ESCO 80A/1.5mm Full-Face Flange Gasket, Heat/Steam Resistant/5K EA351GG-80
JAN
4550061543092
ASIN
B092QV3LHD
Maker
Model No.
EA351GG-80
Color
Size
Description
Description
▪️Nominal Diameter…80A
▪️Thickness…1.5mm
▪️Operating Temperature Range…Water-based fluids: -100 to 215°C Oil-based fluids: -100 to 150°C Gas-based fluids: -100 to 200°C
▪️Material…Special blend rubber, aramid fiber, inorganic filler
▪️Applicable Fluids…Water, steam, hot water, brine, seawater, petroleum hydrocarbons, alcohol, vegetable/animal oils, heat transfer oil, weak acids, weak alkalis, salt solutions, air, exhaust gases, etc.
▪️Maximum Pressure…Water-based/Oil-based Fluids: 3.0MPa Gas-based Fluids: 1.0MPa
▪️Full-face packing
▪️JIS5K
▪️Excellent heat and steam resistance, suitable for steam lines
Brand Name: Esco
Nominal Diameter…80A
Thickness…1.5mm
Operating Temperature Range…Water-based Fluids: -100 to 215°C Oil-based Fluids: -100 to 150°C Gas-based Fluids: -100 to 200°C
Material…Special blend rubber, aramid fiber, inorganic filler
Applicable fluids…Water, steam, hot water, brine, seawater, petroleum hydrocarbons, alcohol, vegetable/animal oils, heat transfer oil, weak acids, weak alkalis, salt solutions, air, exhaust gases, etc.
4550061543092
ESCO 80A/1.5mm Full-Face Flange Packing Heat Resistant/Steam Resistant/5K EA351GG-80
(text created at , 2025-05-09)
▪️Nominal Diameter…80A
▪️Thickness…1.5mm
▪️Operating Temperature Range…Water-based fluids: -100 to 215°C Oil-based fluids: -100 to 150°C Gas-based fluids: -100 to 200°C
▪️Material…Special blend rubber, aramid fiber, inorganic filler
▪️Applicable Fluids…Water, steam, hot water, brine, seawater, petroleum hydrocarbons, alcohol, vegetable/animal oils, heat transfer oil, weak acids, weak alkalis, salt solutions, air, exhaust gases, etc.
▪️Maximum Pressure…Water-based/Oil-based Fluids: 3.0MPa Gas-based Fluids: 1.0MPa
▪️Full-face packing
▪️JIS5K
▪️Excellent heat and steam resistance, suitable for steam lines
Brand Name: Esco
Nominal Diameter…80A
Thickness…1.5mm
Operating Temperature Range…Water-based Fluids: -100 to 215°C Oil-based Fluids: -100 to 150°C Gas-based Fluids: -100 to 200°C
Material…Special blend rubber, aramid fiber, inorganic filler
Applicable fluids…Water, steam, hot water, brine, seawater, petroleum hydrocarbons, alcohol, vegetable/animal oils, heat transfer oil, weak acids, weak alkalis, salt solutions, air, exhaust gases, etc.
4550061543092
ESCO 80A/1.5mm Full-Face Flange Packing Heat Resistant/Steam Resistant/5K EA351GG-80
(text created at , 2025-05-09)
