ESCO 125A/2.0mm Internal Flange Gasket, Heat/Steam Resistant/10K EA351FH-125
JAN
4550061546260
ASIN
B092QWKT2Q
Manufacturer
Model Number
EA351FH-125
Color
Size
Description
ESCO-Internal Flange Gasket-Heat/Steam Resistant-EA351FH-125
▪️Internal Flange Gasket
▪️For JIS Pipe Flanges
▪️JIS 10K
▪️Operating Temperature Range…Water-based Fluids: -100~215℃ Oil-based Fluids: -100~150℃ Gas-based Fluids: -100~200℃
▪️This flange gasket is machined from a deep green NA (non-asbestos) joint sheet. It contains no asbestos whatsoever and incorporates carbon fiber—known for its superior heat resistance—alongside inorganic fibers and aramid fibers. A special rubber with excellent heat and steam resistance serves as both the inorganic filler and binder.
▪️Low soluble halogen content makes it suitable for stainless steel flanges.
▪️Nominal Diameter…125A
▪️Thickness…2.0mm
Brand Name: Esco
Inner Flange Gasket
For JIS Pipe Flanges
JIS 10K
Operating Temperature Range…Water-based Fluids: -100 to 215°C Oil-based Fluids: -100 to 150°C Gas-based Fluids: -100 to 200°C
This flange gasket is machined from a deep green NA (non-asbestos) joint sheet. It contains no asbestos whatsoever and incorporates carbon fiber for superior heat resistance, in addition to inorganic fibers and aramid fibers. It also blends a special rubber with excellent heat and steam resistance as the inorganic filler and binder.
4550061546260
ESCO 125A/2.0mm Inner Flange Gasket Heat/Steam Resistant/10K EA351FH-125
(text created at , 2025-05-10)
▪️Internal Flange Gasket
▪️For JIS Pipe Flanges
▪️JIS 10K
▪️Operating Temperature Range…Water-based Fluids: -100~215℃ Oil-based Fluids: -100~150℃ Gas-based Fluids: -100~200℃
▪️This flange gasket is machined from a deep green NA (non-asbestos) joint sheet. It contains no asbestos whatsoever and incorporates carbon fiber—known for its superior heat resistance—alongside inorganic fibers and aramid fibers. A special rubber with excellent heat and steam resistance serves as both the inorganic filler and binder.
▪️Low soluble halogen content makes it suitable for stainless steel flanges.
▪️Nominal Diameter…125A
▪️Thickness…2.0mm
Brand Name: Esco
Inner Flange Gasket
For JIS Pipe Flanges
JIS 10K
Operating Temperature Range…Water-based Fluids: -100 to 215°C Oil-based Fluids: -100 to 150°C Gas-based Fluids: -100 to 200°C
This flange gasket is machined from a deep green NA (non-asbestos) joint sheet. It contains no asbestos whatsoever and incorporates carbon fiber for superior heat resistance, in addition to inorganic fibers and aramid fibers. It also blends a special rubber with excellent heat and steam resistance as the inorganic filler and binder.
4550061546260
ESCO 125A/2.0mm Inner Flange Gasket Heat/Steam Resistant/10K EA351FH-125
(text created at , 2025-05-10)
Package
Size (Approx.):
Size (Approx.):
- mm
Package
Weight (Approx.):
Weight (Approx.):
- g
2,014 JPY (Including Tax)
