ESCO 40A/1.5mm Full-Face Flange Gasket, Heat/Steam Resistant/10K EA351GK-40
JAN
4550061547373
ASIN
B092QV53HK
Maker
Model No.
EA351GK-40
Color
Size
Description
▪️Nominal Diameter…40A
▪️Thickness…1.5mm
▪️Operating Temperature Range…Water-based fluids: -100 to 215°C Oil-based fluids: -100 to 150°C Gas-based fluids: -100 to 200°C
▪️Maximum Pressure…Water/oil-based fluids: 3.0MPa Gas-based fluids: 1.0MPa
▪️Applicable Fluids…Water, steam, hot water, brine, seawater, petroleum hydrocarbons, alcohol, vegetable/animal oils, heat transfer oil, weak acids, weak alkalis, salt solutions, air, exhaust gas, etc.
▪️Material…Special blend rubber, aramid fiber, inorganic filler
▪️Full-face packing
▪️JIS 10K
▪️Excellent heat and steam resistance, suitable for steam lines
Brand Name: Esco
Nominal Diameter…40A
Thickness…1.5mm
Operating Temperature Range…Water-based Fluids: -100 to 215°C Oil-based Fluids: -100 to 150°C Gas-based Fluids: -100 to 200°C
Maximum Pressure…Water/Oil-based Fluids: 3.0MPa Gas-based Fluids: 1.0MPa
Applicable Fluids…Water, Steam, Hot Water, Brine, Seawater, Petroleum Hydrocarbons, Alcohol, Vegetable/Animal Oils, Heat Transfer Oil, Weak Acids, Weak Alkalis, Salt Solutions, Air, Exhaust Gas, etc.
4550061547373
ESCO 40A/1.5mm Full-Face Flange Gasket Heat/Steam Resistant/10K EA351GK-40
(text created at , 2025-05-11)
▪️Thickness…1.5mm
▪️Operating Temperature Range…Water-based fluids: -100 to 215°C Oil-based fluids: -100 to 150°C Gas-based fluids: -100 to 200°C
▪️Maximum Pressure…Water/oil-based fluids: 3.0MPa Gas-based fluids: 1.0MPa
▪️Applicable Fluids…Water, steam, hot water, brine, seawater, petroleum hydrocarbons, alcohol, vegetable/animal oils, heat transfer oil, weak acids, weak alkalis, salt solutions, air, exhaust gas, etc.
▪️Material…Special blend rubber, aramid fiber, inorganic filler
▪️Full-face packing
▪️JIS 10K
▪️Excellent heat and steam resistance, suitable for steam lines
Brand Name: Esco
Nominal Diameter…40A
Thickness…1.5mm
Operating Temperature Range…Water-based Fluids: -100 to 215°C Oil-based Fluids: -100 to 150°C Gas-based Fluids: -100 to 200°C
Maximum Pressure…Water/Oil-based Fluids: 3.0MPa Gas-based Fluids: 1.0MPa
Applicable Fluids…Water, Steam, Hot Water, Brine, Seawater, Petroleum Hydrocarbons, Alcohol, Vegetable/Animal Oils, Heat Transfer Oil, Weak Acids, Weak Alkalis, Salt Solutions, Air, Exhaust Gas, etc.
4550061547373
ESCO 40A/1.5mm Full-Face Flange Gasket Heat/Steam Resistant/10K EA351GK-40
(text created at , 2025-05-11)
Package
Size (Approx.):
Size (Approx.):
- mm
Package
Weight (Approx.):
Weight (Approx.):
- g
1,040 JPY (Including Tax)
Stock :
6
Scheduled Shipping:
2026-04-08
