ESCO 10A/3.0mm Full-Face Flange Gasket, High Temperature Use/10K EA351GW-10
JAN
4550061550977
ASIN
B092QVCX1D
Maker
Model No.
EA351GW-10
Color
Size
Description
▪️Nominal Diameter…10A
▪️Thickness…3.0mm
▪️Operating Temperature Range…Water-based fluids: -200 to 215°C Oil-based/gas-based fluids: -200 to 260°C
▪️Maximum Pressure…Water-based/oil-based fluids: 4.0MPa Gas-based fluids: 1.0MPa
▪️Materials…NBR, aramid fiber, expanded graphite
▪️Applicable Fluids…Water, steam, hot water, petroleum hydrocarbons, alcohol, vegetable/animal oils, heat transfer oils, aromatic hydrocarbons, organic solvents, weak acids, weak alkalis, salt solutions, air, exhaust gases, etc.
▪️Full-face packing
▪️JIS 10K
▪️Excellent heat resistance, steam resistance, and corrosion resistance due to expanded graphite as the main component
▪️Resistant to scratching and highly flexible
▪️Used for relatively high-temperature flanges, valves, and equipment
Brand Name: Esco
Nominal Diameter…10A
Thickness…3.0mm
Operating Temperature Range…Water-based fluids: -200 to 215°C Oil-based/gas-based fluids: -200 to 260°C
Maximum Pressure…Water/oil-based fluids: 4.0MPa Gas-based fluids: 1.0MPa
Material…NBR, aramid fiber, expanded graphite
4550061550977
ESCO 10A/3.0mm Full-Face Flange Gasket for High Temperatures/10K EA351GW-10
(text created at , 2025-05-11)
▪️Thickness…3.0mm
▪️Operating Temperature Range…Water-based fluids: -200 to 215°C Oil-based/gas-based fluids: -200 to 260°C
▪️Maximum Pressure…Water-based/oil-based fluids: 4.0MPa Gas-based fluids: 1.0MPa
▪️Materials…NBR, aramid fiber, expanded graphite
▪️Applicable Fluids…Water, steam, hot water, petroleum hydrocarbons, alcohol, vegetable/animal oils, heat transfer oils, aromatic hydrocarbons, organic solvents, weak acids, weak alkalis, salt solutions, air, exhaust gases, etc.
▪️Full-face packing
▪️JIS 10K
▪️Excellent heat resistance, steam resistance, and corrosion resistance due to expanded graphite as the main component
▪️Resistant to scratching and highly flexible
▪️Used for relatively high-temperature flanges, valves, and equipment
Brand Name: Esco
Nominal Diameter…10A
Thickness…3.0mm
Operating Temperature Range…Water-based fluids: -200 to 215°C Oil-based/gas-based fluids: -200 to 260°C
Maximum Pressure…Water/oil-based fluids: 4.0MPa Gas-based fluids: 1.0MPa
Material…NBR, aramid fiber, expanded graphite
4550061550977
ESCO 10A/3.0mm Full-Face Flange Gasket for High Temperatures/10K EA351GW-10
(text created at , 2025-05-11)
Package
Size (Approx.):
Size (Approx.):
- mm
Package
Weight (Approx.):
Weight (Approx.):
- g
1,126 JPY (Including Tax)
Stock :
1
Scheduled Shipping:
2026-02-12
Quantity :
Reference Price from Other Stores
