ESCO 15A/3.0mm Full-Face Flange Gasket 5K EA351GC-15
JAN
4550061552384
ASIN
B092QTP8XV
Maker
Model No.
EA351GC-15
Color
Size
Description
ESCO-3-0mm-Full-Face Flange Gasket-EA351GC-15
▪️Nominal Diameter…15A
▪️Thickness…3.0mm
▪️Operating Temperature Range…Water-based fluids: -100~183℃ Oil-based fluids: -100~180℃ Gas-based fluids: -100~180℃
▪️Material…NBR, aramid fiber, inorganic filler
▪️Applicable Fluids…Water, steam, hot water, brine, seawater, petroleum hydrocarbons, alcohol, vegetable/animal oils, heat transfer oil, weak acids, weak alkalis, salt solutions, air, exhaust gas, etc.
▪️Maximum Pressure…Water-based/Oil-based Fluids: 3.0MPa Gas-based Fluids: 1.0MPa
▪️Full-face packing
▪️JIS5K
▪️Used in relatively low-temperature equipment
Brand Name: Esco
Nominal Diameter…15A
Thickness…3.0mm
Operating temperature range…Water-based fluids: -100 to 183°C Oil-based fluids: -100 to 180°C Gas-based fluids: -100 to 180°C
Material…NBR, aramid fiber, inorganic filler
Applicable fluids…Water, steam, hot water, brine, seawater, petroleum hydrocarbons, alcohol, vegetable/animal oils, heat transfer oil, weak acids, weak alkalis, salt solutions, air, exhaust gas, etc.
4550061552384
ESCO 15A/3.0mm Full Face Flange Gasket 5K EA351GC-15
(text created at , 2025-05-11)
▪️Nominal Diameter…15A
▪️Thickness…3.0mm
▪️Operating Temperature Range…Water-based fluids: -100~183℃ Oil-based fluids: -100~180℃ Gas-based fluids: -100~180℃
▪️Material…NBR, aramid fiber, inorganic filler
▪️Applicable Fluids…Water, steam, hot water, brine, seawater, petroleum hydrocarbons, alcohol, vegetable/animal oils, heat transfer oil, weak acids, weak alkalis, salt solutions, air, exhaust gas, etc.
▪️Maximum Pressure…Water-based/Oil-based Fluids: 3.0MPa Gas-based Fluids: 1.0MPa
▪️Full-face packing
▪️JIS5K
▪️Used in relatively low-temperature equipment
Brand Name: Esco
Nominal Diameter…15A
Thickness…3.0mm
Operating temperature range…Water-based fluids: -100 to 183°C Oil-based fluids: -100 to 180°C Gas-based fluids: -100 to 180°C
Material…NBR, aramid fiber, inorganic filler
Applicable fluids…Water, steam, hot water, brine, seawater, petroleum hydrocarbons, alcohol, vegetable/animal oils, heat transfer oil, weak acids, weak alkalis, salt solutions, air, exhaust gas, etc.
4550061552384
ESCO 15A/3.0mm Full Face Flange Gasket 5K EA351GC-15
(text created at , 2025-05-11)
Package
Size (Approx.):
Size (Approx.):
- mm
Package
Weight (Approx.):
Weight (Approx.):
- g
412 JPY (Including Tax)
Stock :
6
Scheduled Shipping:
2026-02-12
