ESCO 65A/3.0mm Full-Face Flange Gasket, High Temperature Use/5K EA351GS-65
JAN
4550061554791
ASIN
B092QW84N2
Maker
Model No.
EA351GS-65
Color
Size
Description
▪️Nominal Diameter…65A
▪️Thickness…3.0mm
▪️Operating Temperature Range…Water-based fluids: -200 to 215°C Oil-based/gas-based fluids: -200 to 260°C
▪️Materials…NBR, aramid fiber, expanded graphite
▪️Applicable Fluids…Water, steam, hot water, petroleum hydrocarbons, alcohol, vegetable/animal oils, heat transfer oils, aromatic hydrocarbons, organic solvents, weak acids, weak alkalis, salt solutions, air, exhaust gases, etc.
▪️Maximum Pressure…Water-based/oil-based fluids: 4.0MPa Gas-based fluids: 1.0MPa
▪️Full-face packing
▪️JIS5K
▪️Composed primarily of expanded graphite, offering excellent heat resistance, steam resistance, and corrosion resistance
▪️Resistant to scratching and highly flexible
▪️Used in relatively high-temperature flanges, valves, and equipment
Brand Name: Esco
Nominal Diameter…65A
Thickness…3.0mm
Operating Temperature Range…Water-based fluids: -200 to 215°C Oil-based/gas-based fluids: -200 to 260°C
Material…NBR, aramid fiber, expanded graphite
Applicable Fluids…Water, steam, hot water, petroleum hydrocarbons, alcohol, vegetable/animal oils, heat transfer oil, aromatic hydrocarbons, organic solvents, weak acids, weak alkalis, salt solutions, air, exhaust gases, etc.
4550061554791
ESCO 65A/3.0mm Full Face Flange Gasket for High Temperature/5K EA351GS-65
(text created at , 2025-05-09)
▪️Thickness…3.0mm
▪️Operating Temperature Range…Water-based fluids: -200 to 215°C Oil-based/gas-based fluids: -200 to 260°C
▪️Materials…NBR, aramid fiber, expanded graphite
▪️Applicable Fluids…Water, steam, hot water, petroleum hydrocarbons, alcohol, vegetable/animal oils, heat transfer oils, aromatic hydrocarbons, organic solvents, weak acids, weak alkalis, salt solutions, air, exhaust gases, etc.
▪️Maximum Pressure…Water-based/oil-based fluids: 4.0MPa Gas-based fluids: 1.0MPa
▪️Full-face packing
▪️JIS5K
▪️Composed primarily of expanded graphite, offering excellent heat resistance, steam resistance, and corrosion resistance
▪️Resistant to scratching and highly flexible
▪️Used in relatively high-temperature flanges, valves, and equipment
Brand Name: Esco
Nominal Diameter…65A
Thickness…3.0mm
Operating Temperature Range…Water-based fluids: -200 to 215°C Oil-based/gas-based fluids: -200 to 260°C
Material…NBR, aramid fiber, expanded graphite
Applicable Fluids…Water, steam, hot water, petroleum hydrocarbons, alcohol, vegetable/animal oils, heat transfer oil, aromatic hydrocarbons, organic solvents, weak acids, weak alkalis, salt solutions, air, exhaust gases, etc.
4550061554791
ESCO 65A/3.0mm Full Face Flange Gasket for High Temperature/5K EA351GS-65
(text created at , 2025-05-09)
