ESCO 50A/1.5mm Full-Face Flange Gasket 10K EA351GD-50
JAN
4550061558034
ASIN
B092QS59KV
Manufacturer
Model Number
EA351GD-50
Color
Size
Description
ESCO-ESCO-1-5mm-Full-Face Flange Gasket-EA351GD-50
▪️Thickness…1.5mm
▪️Nominal Diameter…50A
▪️Operating Temperature Range…Water-based fluids: -100~183℃ Oil-based fluids: -100~180℃ Gas-based fluids: -100~180℃
▪️Material…NBR, aramid fiber, inorganic filler
▪️Applicable Fluids…Water-based, steam, chemical-based, oil-based, exhaust gas, etc.
▪️Maximum Pressure…Water/oil-based fluids: 3.0MPa Gas-based fluids: 1.0MPa
▪️Large-diameter gasket.
▪️Can be manufactured seamlessly up to 3810×3810mm (9S size).
▪️Used for relatively low-temperature flanges, valves, and equipment.
▪️Full-face packing
▪️JIS10K
Brand Name: Esco
Thickness…1.5mm
Nominal Diameter…50A
Operating Temperature Range…Water-based fluids: -100 to 183°C Oil-based fluids: -100 to 180°C Gas-based fluids: -100 to 180°C
Material…NBR, aramid fiber, inorganic filler
Applicable Fluids…Water-based, steam, chemical-based, oil-based, exhaust gas, etc.
4550061558034
ESCO 50A/1.5mm Full-Face Flange Gasket 10K EA351GD-50
(text created at , 2025-05-12)
▪️Thickness…1.5mm
▪️Nominal Diameter…50A
▪️Operating Temperature Range…Water-based fluids: -100~183℃ Oil-based fluids: -100~180℃ Gas-based fluids: -100~180℃
▪️Material…NBR, aramid fiber, inorganic filler
▪️Applicable Fluids…Water-based, steam, chemical-based, oil-based, exhaust gas, etc.
▪️Maximum Pressure…Water/oil-based fluids: 3.0MPa Gas-based fluids: 1.0MPa
▪️Large-diameter gasket.
▪️Can be manufactured seamlessly up to 3810×3810mm (9S size).
▪️Used for relatively low-temperature flanges, valves, and equipment.
▪️Full-face packing
▪️JIS10K
Brand Name: Esco
Thickness…1.5mm
Nominal Diameter…50A
Operating Temperature Range…Water-based fluids: -100 to 183°C Oil-based fluids: -100 to 180°C Gas-based fluids: -100 to 180°C
Material…NBR, aramid fiber, inorganic filler
Applicable Fluids…Water-based, steam, chemical-based, oil-based, exhaust gas, etc.
4550061558034
ESCO 50A/1.5mm Full-Face Flange Gasket 10K EA351GD-50
(text created at , 2025-05-12)
Package
Size (Approx.):
Size (Approx.):
- mm
Package
Weight (Approx.):
Weight (Approx.):
- g
1,254 JPY (Including Tax)
Stock :
12
Scheduled Shipping:
2025-12-01
Quantity :
