1/2" Lock Lever Damper (Aluminum)
JAN
4550061563533
ASIN
B092QWQHGL
Maker
Model No.
EA470ED-14
Color
Size
JIS B2032
Description
▪️Nominal Diameter…A designation: 40 B designation: 1-1/2
▪️Material…Body: ADC12 Stem: SUS410 Disc: SCS13A Handle: ADC12 O-ring: EPDM Seat rubber: EPDM (insert type)
▪️Maximum Working Pressure…1.0MPa
▪️Applicable Flange Standard…5K/10K (JIS)
▪️Operating Temperature Range…-20~100℃
▪️Face-to-Face Dimension…JIS B2032
▪️Lock Lever Type
Brand Name: Esco
Material: EPDM
Nominal Diameter…A Nominal: 40 B Nominal: 1-1/2
Material…Body: ADC12 Stem: SUS410 Disc: SCS13A Handle: ADC12 O-ring: EPDM Seat rubber: EPDM (insert type)
Maximum operating pressure…1.0MPa
Applicable flange standard…5K/10K (JIS)
Operating temperature range…-20 to 100℃
4550061563533
“1-1/2” “Lock Lever Type Damper (Aluminum)”
(text created at , 2025-05-10)
▪️Material…Body: ADC12 Stem: SUS410 Disc: SCS13A Handle: ADC12 O-ring: EPDM Seat rubber: EPDM (insert type)
▪️Maximum Working Pressure…1.0MPa
▪️Applicable Flange Standard…5K/10K (JIS)
▪️Operating Temperature Range…-20~100℃
▪️Face-to-Face Dimension…JIS B2032
▪️Lock Lever Type
Brand Name: Esco
Material: EPDM
Nominal Diameter…A Nominal: 40 B Nominal: 1-1/2
Material…Body: ADC12 Stem: SUS410 Disc: SCS13A Handle: ADC12 O-ring: EPDM Seat rubber: EPDM (insert type)
Maximum operating pressure…1.0MPa
Applicable flange standard…5K/10K (JIS)
Operating temperature range…-20 to 100℃
4550061563533
“1-1/2” “Lock Lever Type Damper (Aluminum)”
(text created at , 2025-05-10)
Package
Size (Approx.):
Size (Approx.):
- mm
Package
Weight (Approx.):
Weight (Approx.):
- g
6,420 JPY (Including Tax)
Stock :
1
Scheduled Shipping:
2026-03-27
Quantity :
