ESCO 150A/3.0mm Full Flange Gasket 10K EA351GF-150

4550061564578

B092QVNCBC

EA351GF-150

▪️Thickness…3.0mm
▪️Nominal Diameter…150A
▪️Operating Temperature Range…Water-based fluids: -100 to 183°C Oil-based fluids: -100 to 180°C Gas-based fluids: -100 to 180°C
▪️Materials…NBR, aramid fiber, inorganic filler
▪️ Applicable Fluids…Water-based, steam, chemical-based, oil-based, exhaust gas, etc.
▪️Maximum Pressure…Water-based/oil-based fluids: 3.0MPa Gas-based fluids: 1.0MPa
▪️Large-diameter gasket.
▪️Can be manufactured seamlessly up to 3810×3810mm (9S size).
▪️Used for relatively low-temperature flanges, valves, and equipment.
▪️ Full-face packing
▪️ JIS 10K

Brand Name: Esco
Thickness…3.0mm
Nominal Diameter…150A
Operating Temperature Range…Water-based fluids: -100 to 183°C Oil-based fluids: -100 to 180°C Gas-based fluids: -100 to 180°C
Material…NBR, aramid fiber, inorganic filler
Applicable fluids…Water-based, steam, chemical-based, oil-based, exhaust gas, etc.
4550061564578
ESCO 150A/3.0mm Full Face Flange Gasket 10K EA351GF-150
