ESCO Ring Joint with Lock Nuts on Both Ends 12x12mm EA426AS-6

4550061986622

B0BWR25V1L

EA426AS-6

ESCO Ring Joint - Dual Lock Nut - 12x12mm - EA426AS-6

▪️ Copper Tube Outer Diameter: 12mm
▪️ Operating Temperature Range: -50~150℃
▪️ Compatible Fluids: Air, Water, Oil
▪️Operating Pressure: 3.45MPa or less
▪️Weight (g): 177
▪️Hexagon Diagonal (mm): 22
▪️Nut Hexagon Diagonal (mm): 24
▪️Lock Nut Hexagon Diagonal (mm): 23
▪️(Approx.) Overall Length (mm): 73
▪️Material: C3604BD
▪️Equipped with lock nuts on both ends
▪️This ring joint connects copper pipes separated by a wall or panel.
▪️Connection is possible without specialized tools.
※※Product for business use only※※
Brand Name: Esco
Copper Pipe Outer Diameter: 12mm
Operating Temperature Range: -50 to 150°C
Fluid: Air, Water, Oil
Pressure Rating: 3.45MPa or less
Weight (g): 177
Hexagon Diagonal (mm): 22
Nut Hexagon Diagonal (mm): 24
Lock Nut Hexagon Diagonal (mm): 23
(Approx.) Overall Length (mm): 73
Material: C3604BD
4550061986622
ESCO Ring Joint with Dual Lock Nuts 12x12mm EA426AS-6
