ELECOM LAN Cable CAT6A 1m Anti-Snapping Connector Standard Blue LD-GPA/BU1

4953103221871

B002K6ETXQ

LD-GPA/BU1

ELECOM LAN Cable - [PlayStation-LD-GPA-BU1]

■ Cable Length: Approx. 1m (excluding connectors)

■ Color: Blue

■ Cable Diameter: Approx. 6.5mm

■ Wiring Method: Straight-through wiring

■ Conductor Composition: Stranded wire (24AWG)

■Conductor Construction: Stranded Wire (24AWG)\


■Outer Sheath Material: PVC\


■Transmission Speed: 10Gbps\


■Interface: RJ-45 Connector\


■Environmental Compliance: EU RoHS Directive Compliant (10 Substances)\


■PoE: No\


■Standard: Cat6A compliant (supports 10BASE-T, 100BASE-TX, 1000BASE-T, 1000BASE-TX, 10GBASE-T)\


■Transmission Bandwidth: 500MHz\


■Number of Cores: 8 cores\


■Cross-over: Yes\


■Connector Presence: Connectors on both ends\


■Slim Connector: Yes\


■Connector with Non-breakable Tabs: No\


■Connector with Tab-break Prevention Cover: Yes\


■Cable Winding Function: No\


■Package Type: Aluminum foil bag + sticker\
\


■This Cat6A compliant LAN cable supports 10GBASE-T, suitable for high-speed optical communication.\


■It supports a high-frequency bandwidth up to 500MHz, twice that of Cat6, offering strong resistance to noise interference and enabling a fast, stable network environment.\


■Ensures stable data transfer speeds in 1000BASE-TX/1000BASE-T/100BASE-T environments.\


■Features a double-layered structure with a clip-break prevention protector and a connector made from highly durable material resistant to bending, making it a LAN cable less prone to clip breakage. *Passed 1000 bend tests (in-house verification)\


■Features a slim connector that minimizes protrusion and avoids interference with adjacent ports.\


■Incorporates a cross-shaped dielectric material within the cable to prevent signal interference and ensure stable data transfer.\


■Features twisted-pair construction for greater flexibility and easier handling compared to solid-core cables.\


■Environmentally friendly product compliant with the EU's RoHS Directive (Restriction of Hazardous Substances in Electrical and Electronic Equipment) covering 10 substances.\


■Meets at least one of our company's environmental certification standards and displays the ‘THINK ECOLOGY’ mark.\


■Committed to environmental conservation, this product's packaging consists solely of paper, cardboard, and poly bags.\
ELECOM General Information Center\
TEL. 0570-084-465\
FAX. 0570-050-012\
Hours: 10:00 AM - 7:00 PM, Open Year-Round\
Brand Name: ELECOM\
Unit Only\
This Cat6A compliant LAN cable supports “10GBASE-T” 10 Gigabit Ethernet, ideal for high-speed optical communication.

110x18x218 mm

50 g
