ELECOM Wi-Fi Wireless LAN Adapter 433Mbps 11ac/n/a 5GHz Dedicated USB 2.0 Compact Model Black WDC-433SU2M2BK

4953103473003

B01DZCO8D4

243-7743

ELECOM - 433Mbps - 5GHz Only - Compact Model - WDC-433SU2M2BK Product Introduction



■Wireless LAN Standard: IEEE802.11ac (5GHz band) / IEEE802.11n (5GHz band) / IEEE802.11a (5GHz band)


■Interface: USB 2.0 *This product must be connected directly to a PC. It is not compatible with a USB hub.

■Frequency (Center Frequency): 5.2GHz band: 5.15-5.25GHz, 5.3GHz band: 5.25-5.35GHz, 5.6GHz band: 5.47-5.725GHz

■Channel: 5GHz band (W52/W53/W56): 36/40/44/48/52/56/60/64/100/104/108/112/116/120/124/128/132/136/140ch

■Transmission Method: IEEE802.11ac: OFDM / IEEE802.11n: OFDM / IEEE802.11a: OFDM

■Transmission Speed (Theoretical): Maximum 433Mbps

■Transmit Power: Less than 10mW/MHz

■Security: WPA2-PSK (AES : 128bit), WPA-PSK (TKIP), WEP (128/64bit) Access Method: Infrastructure / Ad-hoc *1 / Software AP *2 *1 Mac OS and Windows 10/8.1/8 do not support Ad-hoc mode. *2 Mac OS and Windows 10S/10/7/Vista do not support Software AP mode (parent device).

■Setup method: WPS (software method)

■Environmental conditions: Temperature: 0 to 40°C, Humidity: 20 to 80% (no condensation)

■Current consumption (maximum): 176mA

■External dimensions: (W) approx. 19 x (D) approx. 15 x (H) approx. 8mm

■Weight: Approx. 2g

■Housing material (color): Plastic (black)

■Approved standards: VCCI Class B, TELEC

■Warranty period: 1 year

■Accessories: Easy setup guide, CD-ROM *If you are using Windows 11, please download the driver from the Web.

■Compatible OS: Windows 11 (64-bit), Windows 10S (32/64-bit), 10 (32/64-bit), 8.1 (32/64-bit), 8 (32/64-bit), 7 SP1 or later (32/64-bit), Vista SP2 or later (32-bit), XP SP3 or later, Mac OS X 10.10/10.9/10.8/10.7/10.6 (Windows 10S is driverless)

■Easily upgrade your PC with 5GHz wireless communication, resistant to radio interference, and ultra-fast 11ac speeds of up to 433Mbps. (11n/g/b (2.4GHz) communication is not supported. Use in conjunction with an 11ac/n/a (5GHz) wireless router.

■World's smallest and lightest class*, protruding only 10mm when attached to a PC. This means you can easily carry it around with the driver plugged into your laptop without any issues. (As of June 25, 2015, according to our research.)

■ For environments without internet access, you can install the driver from the included CD-ROM. For Ultrabooks™ without CD-ROM drives, you can download the driver from our website. *Internet access via a wired LAN or the computer's built-in wireless adapter is required. Please check our website. Disclaimer: Please Read. *A USB 2.0 or higher port is required. *Mac OS X is only compatible with machines equipped with an Intel CPU. Brand: ELECOM Easy Setup Guide, CD-ROM. With 5GHz communication, it is resistant to radio interference, and 11ac supports ultra-high-speed communication of up to 433Mbps, making it easy to upgrade your computer. *Not compatible with 11n/g/b (2.4GHz) communication. Use in conjunction with an 11ac/n/a (5GHz) compatible wireless LAN router. It is the smallest and lightest in the world (*), and when attached to a PC, it only protrudes 10mm. So, you can carry it around with it plugged into your laptop without it being a nuisance. (*As of June 25, 2015, according to our research) In environments without internet access, you can use the included CD-ROM, and for Ultrabooks™ without CD-ROM drives, you can download the driver from our website, and you can choose how to install it depending on your environment.

135x30x180 mm

110 g
