Sanwa Supply 4K-Compatible HDMI PC Auto Switch (2:1) SW-KVM2U3HD
JAN
4969887595183
ASIN
B0BGS3S141
Maker
Model No.
SW-KVM2U3HD
Color
Size
Description
Sanwa Supply - 4K-Compatible HDMI PC Auto Switching Unit - 2-1-SW-KVM2U3HD
▪️Allows switching between two PCs using a single set of HDMI display, USB keyboard, and USB mouse.\
▪️ Supports 4K (3840×2160)/60Hz and 4K (4096×2160)/60Hz resolutions, outputting beautiful, high-definition HDMI signals.\
▪️ Features display emulation (EDID readout circuitry). It reads the display's EDID and stores it in the KVM. By responding to each port during DDC communication, it prevents issues like screen resolution or size changes during background startup.\
▪️HDCP support allows playback of copyright-protected content like digital terrestrial broadcasts and Blu-ray media.\
▪️Equipped with a 2-port USB 3.2 Gen1 hub, enabling sharing of various USB devices like card readers or printers between two computers. Additionally, independent switching is possible, allowing you to operate USB devices on one computer while working on another.\
▪️Speaker sharing is also possible. Independent switching is supported, allowing separate switching of the console device and speakers. You can play music from one computer while working on another, or monitor work status via audio.\
▪️Independent switching is possible for KVM, USB 3.2 Gen1 hub, and audio.\
▪️ Keyboard port emulation enables full system startup without port switching during reboot.\
▪️ Supports two switching methods: hotkeys and the unit's physical switch button.\
▪️ Mouse and keyboard only connections are possible. (HDMI display connects directly to the PC)\
▪️ HDMI-only connections are possible. (Keyboard/mouse not connected. AC adapter connection required. Only button switching operation is supported.)\
▪️No software installation required; all functions are available simply by connecting.\
▪️Features auto-scan functionality to monitor all connected computers.\
▪️Includes an audio mix mode capable of simultaneously outputting a mix of up to two audio sources. System warning sounds can be checked even while switching ports.\
【 Important Notes 】\
※This product requires an AC adapter connection. It will not operate without connection.\
※Operation is not guaranteed for all PCs, keyboards, or mice.\
※Special buttons or function keys requiring driver installation on keyboards or mice may not function when used via this switch.\
※One-touch resume/suspend functions are not supported.\
■Interfaces: (For PC)\
Display/HDMI (Type A) Female ×2\
Keyboard/Mouse/USB 3.2 Gen1 Hub/USB B Connector Female ×2\
Speaker/3.5mm Stereo Mini Jack ×2\
(Peripheral Side)\
Display/HDMI (Type A) Female ×1\
Keyboard/USB A Connector Female ×1\
Mouse/USB A Connector Female ×1\
USB 3.2 Gen1 Hub/USB A Connector Female ×2\
■Switching Method: Main Unit Button Switching, Hotkey Switching, Auto Scan Switching\
■Power Supply: AC Adapter (DC5V 4A)\
■Current Consumption
▪️Allows switching between two PCs using a single set of HDMI display, USB keyboard, and USB mouse.\
▪️ Supports 4K (3840×2160)/60Hz and 4K (4096×2160)/60Hz resolutions, outputting beautiful, high-definition HDMI signals.\
▪️ Features display emulation (EDID readout circuitry). It reads the display's EDID and stores it in the KVM. By responding to each port during DDC communication, it prevents issues like screen resolution or size changes during background startup.\
▪️HDCP support allows playback of copyright-protected content like digital terrestrial broadcasts and Blu-ray media.\
▪️Equipped with a 2-port USB 3.2 Gen1 hub, enabling sharing of various USB devices like card readers or printers between two computers. Additionally, independent switching is possible, allowing you to operate USB devices on one computer while working on another.\
▪️Speaker sharing is also possible. Independent switching is supported, allowing separate switching of the console device and speakers. You can play music from one computer while working on another, or monitor work status via audio.\
▪️Independent switching is possible for KVM, USB 3.2 Gen1 hub, and audio.\
▪️ Keyboard port emulation enables full system startup without port switching during reboot.\
▪️ Supports two switching methods: hotkeys and the unit's physical switch button.\
▪️ Mouse and keyboard only connections are possible. (HDMI display connects directly to the PC)\
▪️ HDMI-only connections are possible. (Keyboard/mouse not connected. AC adapter connection required. Only button switching operation is supported.)\
▪️No software installation required; all functions are available simply by connecting.\
▪️Features auto-scan functionality to monitor all connected computers.\
▪️Includes an audio mix mode capable of simultaneously outputting a mix of up to two audio sources. System warning sounds can be checked even while switching ports.\
【 Important Notes 】\
※This product requires an AC adapter connection. It will not operate without connection.\
※Operation is not guaranteed for all PCs, keyboards, or mice.\
※Special buttons or function keys requiring driver installation on keyboards or mice may not function when used via this switch.\
※One-touch resume/suspend functions are not supported.\
■Interfaces: (For PC)\
Display/HDMI (Type A) Female ×2\
Keyboard/Mouse/USB 3.2 Gen1 Hub/USB B Connector Female ×2\
Speaker/3.5mm Stereo Mini Jack ×2\
(Peripheral Side)\
Display/HDMI (Type A) Female ×1\
Keyboard/USB A Connector Female ×1\
Mouse/USB A Connector Female ×1\
USB 3.2 Gen1 Hub/USB A Connector Female ×2\
■Switching Method: Main Unit Button Switching, Hotkey Switching, Auto Scan Switching\
■Power Supply: AC Adapter (DC5V 4A)\
■Current Consumption
Package
Size (Approx.):
Size (Approx.):
178x102x285 mm
Package
Weight (Approx.):
Weight (Approx.):
1670 g
73,523 JPY (Including Tax)
Stock :
5
Scheduled Shipping:
2026-04-21
Quantity :
Reference Price from Other Stores
