Sanwa Supply 4-Input 1-Output HDMI Switch (4K Compatible/Seamless Switching/Remote Control Included) SW-UHD41RSL
JAN
4969887596128
ASIN
B0FGWX2XGH
Maker
Model No.
SW-UHD41RSL
Color
Size
Description
Sanwa Supply - 4-Input 1-Output HDMI Switch (4K Compatible - Seamless Switching - Remote Control Included) - SW-UHD41RSL
▪️ This HDMI switch allows you to easily switch and output video and audio from up to four HDMI devices to a single 4K display, 4K projector, or similar device.\
▪️ Supports 4K resolution, enabling beautiful, high-definition HDMI signal output for movies, games, and more.\
▪️ Features seamless switching, displaying video within 1 second after switching. This eliminates lag, ensuring comfortable switching and display.\
▪️ Ideal for meetings or presentations with multiple participants, it enables quick video display during switching for stress-free operation and enhanced productivity.\
▪️Features an auto-scan switching function that automatically cycles through 4 HDMI devices at 5-second intervals, enabling smooth display without manual operation.\
▪️Allows easy port switching from your seat using the remote control, providing comfortable operability.\
▪️Equipped with an up/downscaler function that adjusts output resolution to match the display device's resolution.\
▪️Includes an audio separation function that isolates audio from HDMI signals and outputs it as analog audio. This allows simultaneous output of HDMI video/audio and analog audio.\
▪️All HDMI ports feature gold-plated connectors for corrosion resistance and signal integrity.\
▪️Compatible with Nintendo Switch(TM), PlayStation(R) 4 Pro, and PlayStation(R) 5. (Supported resolution up to 4K/30Hz) 【Important Notes】\
*Operation is not guaranteed with all HDMI devices.\
*“PlayStation”, “PLAYSTATION”, “プレイステーション”, ‘PS5’, and “PS4” are registered trademarks of Sony Computer Entertainment Inc.\
*Nintendo Switch is a trademark or registered trademark of Nintendo.\
■Interface:\
Input/HDMI Type A (19-pin) Female ×4\
Output/HDMI Type A (19-pin) Female ×1\
Audio Output/3.5mm Stereo Mini Jack ×1\
Infrared Remote Control/IR Jack ×1\
■Switching Content: HDMI Input 4, HDMI Output 1\
■Switching Method: Unit Switch Button, Remote Control\
■Maximum Resolution: 4K/30Hz\
■Supported Input Resolutions:\
4096×2160 (30Hz), 3840×2160 (30Hz), 1920×1200 (60Hz)\
1920×1080 (60Hz), 1600×1200 (60Hz), 1440×1050 (60Hz)\
1280×1024 (60Hz), 1360×768 (60Hz), 1280×720 (60Hz), 1024×768 (60Hz)\
*Inputs at resolutions other than those listed above are not supported.\
■Supported Output Resolutions:\
3840×2160 (30Hz), 1920×1080p (60Hz), 1280×720 (60Hz), 1024×768 (60Hz)\
※Output is only possible at the above resolutions. Please ensure your display supports the compatible resolutions.\
■Supported Audio Formats:\
\
Dolby Digital 2/5.1ch, Dolby Digital Plus 2/5.1/7.1ch, Dolby TrueHD 2/5.1/7.1ch, DTS 5.1ch, LPCM 2/5.1/7.1ch\
▪️ This HDMI switch allows you to easily switch and output video and audio from up to four HDMI devices to a single 4K display, 4K projector, or similar device.\
▪️ Supports 4K resolution, enabling beautiful, high-definition HDMI signal output for movies, games, and more.\
▪️ Features seamless switching, displaying video within 1 second after switching. This eliminates lag, ensuring comfortable switching and display.\
▪️ Ideal for meetings or presentations with multiple participants, it enables quick video display during switching for stress-free operation and enhanced productivity.\
▪️Features an auto-scan switching function that automatically cycles through 4 HDMI devices at 5-second intervals, enabling smooth display without manual operation.\
▪️Allows easy port switching from your seat using the remote control, providing comfortable operability.\
▪️Equipped with an up/downscaler function that adjusts output resolution to match the display device's resolution.\
▪️Includes an audio separation function that isolates audio from HDMI signals and outputs it as analog audio. This allows simultaneous output of HDMI video/audio and analog audio.\
▪️All HDMI ports feature gold-plated connectors for corrosion resistance and signal integrity.\
▪️Compatible with Nintendo Switch(TM), PlayStation(R) 4 Pro, and PlayStation(R) 5. (Supported resolution up to 4K/30Hz) 【Important Notes】\
*Operation is not guaranteed with all HDMI devices.\
*“PlayStation”, “PLAYSTATION”, “プレイステーション”, ‘PS5’, and “PS4” are registered trademarks of Sony Computer Entertainment Inc.\
*Nintendo Switch is a trademark or registered trademark of Nintendo.\
■Interface:\
Input/HDMI Type A (19-pin) Female ×4\
Output/HDMI Type A (19-pin) Female ×1\
Audio Output/3.5mm Stereo Mini Jack ×1\
Infrared Remote Control/IR Jack ×1\
■Switching Content: HDMI Input 4, HDMI Output 1\
■Switching Method: Unit Switch Button, Remote Control\
■Maximum Resolution: 4K/30Hz\
■Supported Input Resolutions:\
4096×2160 (30Hz), 3840×2160 (30Hz), 1920×1200 (60Hz)\
1920×1080 (60Hz), 1600×1200 (60Hz), 1440×1050 (60Hz)\
1280×1024 (60Hz), 1360×768 (60Hz), 1280×720 (60Hz), 1024×768 (60Hz)\
*Inputs at resolutions other than those listed above are not supported.\
■Supported Output Resolutions:\
3840×2160 (30Hz), 1920×1080p (60Hz), 1280×720 (60Hz), 1024×768 (60Hz)\
※Output is only possible at the above resolutions. Please ensure your display supports the compatible resolutions.\
■Supported Audio Formats:\
\
Dolby Digital 2/5.1ch, Dolby Digital Plus 2/5.1/7.1ch, Dolby TrueHD 2/5.1/7.1ch, DTS 5.1ch, LPCM 2/5.1/7.1ch\
Package
Size (Approx.):
Size (Approx.):
132x72x245 mm
Package
Weight (Approx.):
Weight (Approx.):
600 g
