Sanwa Supply Armored Single-Core Fiber Optic Cable (Single-Mode, SC-SC, 1m) HKB-AM1SCSC1-01
JAN
4969887758472
ASIN
B0C9CT39C2
Maker
Model No.
HKB-AM1SCSC1-01
Color
Size
Description
Sanwa Supply-HKB-AM1SCSC1-01-Armored Single-Core Fiber Optic Cable (Single-Mode, SC-SC, 1m)
▪️ This OS2-compliant single-mode fiber optic cable enables high-speed, long-distance communication.
▪️ It is a single-core fiber optic cable compatible with optical line ONU devices.
▪️ Capable of transmitting high-frequency signals over a wide bandwidth, it also enables long-distance transmission with low loss.
▪️ With no external electromagnetic induction, it provides complete noise countermeasures.
▪️ Features a high-strength armored structure reinforced internally with a stainless steel spiral, capable of withstanding being stepped on.
■ Cable Color: Blue
■ Cable Length: 1m
■ Fiber Core Diameter: 9μm
■ Fiber Cladding Diameter: 125μm
■ Fiber Type: Single-mode
■Number of Cores: 1 core
■Connector Type: SC connector - SC connector
■Connector Polishing: SPC polishing
■Wavelength: 1310nm, 1550nm
■Transmission Loss: ≤0.4dB/km, ≤0.4dB/km
■Transmission Bandwidth: ≥500MHz·km, ≥500MHz·km
■Standard Outer Diameter: 3.0mm
■Optical Fiber TIA Standard: OS2
■Operating Environment: Indoor Use
■Optical Fiber Classification: General Purpose Single Mode (SM)
■Optical Wavelength: 1310nm, 1550nm
■Minimum Bend Radius: 30mm
Brand Name: Sanwa Supply
This OS2-compliant single-mode optical fiber cable enables high-speed, long-distance communication.
It is a single-core optical fiber cable compatible with fiber-optic line ONU.
It supports high-frequency signal transmission across a wide bandwidth and enables long-distance transmission with low loss.
It is fully noise-resistant due to the absence of external electromagnetic induction.
Its high-strength armored structure, internally reinforced with a stainless steel spiral, can withstand being stepped on.
4969887758472
Sanwa Supply Armored Single-Core Fiber Optic Cable (Single-Mode, SC-SC, 1m) HKB-AM1SCSC1-01
(text created at , 2025-05-12)
▪️ This OS2-compliant single-mode fiber optic cable enables high-speed, long-distance communication.
▪️ It is a single-core fiber optic cable compatible with optical line ONU devices.
▪️ Capable of transmitting high-frequency signals over a wide bandwidth, it also enables long-distance transmission with low loss.
▪️ With no external electromagnetic induction, it provides complete noise countermeasures.
▪️ Features a high-strength armored structure reinforced internally with a stainless steel spiral, capable of withstanding being stepped on.
■ Cable Color: Blue
■ Cable Length: 1m
■ Fiber Core Diameter: 9μm
■ Fiber Cladding Diameter: 125μm
■ Fiber Type: Single-mode
■Number of Cores: 1 core
■Connector Type: SC connector - SC connector
■Connector Polishing: SPC polishing
■Wavelength: 1310nm, 1550nm
■Transmission Loss: ≤0.4dB/km, ≤0.4dB/km
■Transmission Bandwidth: ≥500MHz·km, ≥500MHz·km
■Standard Outer Diameter: 3.0mm
■Optical Fiber TIA Standard: OS2
■Operating Environment: Indoor Use
■Optical Fiber Classification: General Purpose Single Mode (SM)
■Optical Wavelength: 1310nm, 1550nm
■Minimum Bend Radius: 30mm
Brand Name: Sanwa Supply
This OS2-compliant single-mode optical fiber cable enables high-speed, long-distance communication.
It is a single-core optical fiber cable compatible with fiber-optic line ONU.
It supports high-frequency signal transmission across a wide bandwidth and enables long-distance transmission with low loss.
It is fully noise-resistant due to the absence of external electromagnetic induction.
Its high-strength armored structure, internally reinforced with a stainless steel spiral, can withstand being stepped on.
4969887758472
Sanwa Supply Armored Single-Core Fiber Optic Cable (Single-Mode, SC-SC, 1m) HKB-AM1SCSC1-01
(text created at , 2025-05-12)
Package
Size (Approx.):
Size (Approx.):
168x44x236 mm
Package
Weight (Approx.):
Weight (Approx.):
100 g
2,844 JPY (Including Tax)
Stock :
5
Scheduled Shipping:
2026-05-18
Quantity :
Reference Price from Other Stores
