Sanwa Supply HDMI Cable with Latch (10m) KM-HD20-P100L
JAN
4969887770542
ASIN
B0DBVBP1R4
Maker
Model No.
KM-HD20-P100L
Color
Size
Description
Sanwa Supply KM-HD20-P100L HDMI Cable with Latch (10m)
▪️Features a secure latch lock to prevent accidental disconnections from minor vibrations.
▪️Supports 4K, 60Hz, and 18Gbps transmission.
▪️Compatible with 4K2K (60Hz), enabling smooth high-resolution video transmission.
▪️ Supports HDR, enabling transmission of images with enhanced three-dimensionality through dynamic contrast.
▪️ Transmits both video and audio signals digitally at high speed via a single cable, while also enabling bidirectional Ethernet communication.
▪️ Supports ARC (Audio Return Channel), allowing digital audio transmission from display devices like TVs to output devices such as AV amplifiers.
▪️ Supports HDMI Ethernet Channel (HEC). Connects compatible devices via an Ethernet network. ※ Requires compatible devices and environment for each function.
▪️ Shielded twisted pair cable. Each core wire pair (twisted pair cable and drain wire) features a sealed aluminum shield, protecting critical data from external noise. (Only for TMDS twisted pair cables)
▪️Triple shielding structure. From the cable core, it features “aluminum shield (for TMDS twisted pair cables) → aluminum shield → high-density braided shield” for triple shielding, protecting vital data from noise.
▪️Uses gold-plated plugs that are highly resistant to rust and offer low risk of signal degradation due to aging.
■ Cable Length: 10m
■ Connector Type: HDMI Plug - HDMI Plug (HDMI Type A Connector Male-Male)
■Supported Resolutions: 4K (3840×2160)/60Hz, 5K (5120×2880)/30Hz, 1920×1080/60Hz (1080p), 1920×1080/240Hz, 2560×1440/120Hz
■Bandwidth: 18Gbps
■Cable Outer Diameter: 8.3mm
■Type: HDMI 2.0 Compliant
*Not an authorized product.
■Connector (HDMI): Standard (Type A)
■Weight: Approx. 780g
Brand Name: Sanwa Supply
Features a latch lock mechanism to prevent accidental disconnection from minor vibrations.
This cable supports 4K, 60Hz, and 18Gbps transmission.
It supports 4K2K (60Hz), enabling smooth high-resolution video transmission.
It supports HDR, transmitting images with a sense of depth that utilizes contrast between light and dark areas.
A single cable not only transmits video and audio signals digitally at high speed but also enables bidirectional Ethernet signal communication.
4969887770542
Sanwa Supply Latch-Equipped HDMI Cable (10m) KM-HD20-P100L
(text created at , 2025-05-10)
▪️Features a secure latch lock to prevent accidental disconnections from minor vibrations.
▪️Supports 4K, 60Hz, and 18Gbps transmission.
▪️Compatible with 4K2K (60Hz), enabling smooth high-resolution video transmission.
▪️ Supports HDR, enabling transmission of images with enhanced three-dimensionality through dynamic contrast.
▪️ Transmits both video and audio signals digitally at high speed via a single cable, while also enabling bidirectional Ethernet communication.
▪️ Supports ARC (Audio Return Channel), allowing digital audio transmission from display devices like TVs to output devices such as AV amplifiers.
▪️ Supports HDMI Ethernet Channel (HEC). Connects compatible devices via an Ethernet network. ※ Requires compatible devices and environment for each function.
▪️ Shielded twisted pair cable. Each core wire pair (twisted pair cable and drain wire) features a sealed aluminum shield, protecting critical data from external noise. (Only for TMDS twisted pair cables)
▪️Triple shielding structure. From the cable core, it features “aluminum shield (for TMDS twisted pair cables) → aluminum shield → high-density braided shield” for triple shielding, protecting vital data from noise.
▪️Uses gold-plated plugs that are highly resistant to rust and offer low risk of signal degradation due to aging.
■ Cable Length: 10m
■ Connector Type: HDMI Plug - HDMI Plug (HDMI Type A Connector Male-Male)
■Supported Resolutions: 4K (3840×2160)/60Hz, 5K (5120×2880)/30Hz, 1920×1080/60Hz (1080p), 1920×1080/240Hz, 2560×1440/120Hz
■Bandwidth: 18Gbps
■Cable Outer Diameter: 8.3mm
■Type: HDMI 2.0 Compliant
*Not an authorized product.
■Connector (HDMI): Standard (Type A)
■Weight: Approx. 780g
Brand Name: Sanwa Supply
Features a latch lock mechanism to prevent accidental disconnection from minor vibrations.
This cable supports 4K, 60Hz, and 18Gbps transmission.
It supports 4K2K (60Hz), enabling smooth high-resolution video transmission.
It supports HDR, transmitting images with a sense of depth that utilizes contrast between light and dark areas.
A single cable not only transmits video and audio signals digitally at high speed but also enables bidirectional Ethernet signal communication.
4969887770542
Sanwa Supply Latch-Equipped HDMI Cable (10m) KM-HD20-P100L
(text created at , 2025-05-10)
Package
Size (Approx.):
Size (Approx.):
210x65x220 mm
Package
Weight (Approx.):
Weight (Approx.):
910 g
7,774 JPY (Including Tax)
