Sanwa Supply Category 7 LAN Cable (Slim, Flexible, Anti-Snapping Connector, 3m・White) KB-SL7YS-03W

4969887770863

B0D8SXSWH3

KB-SL7YS-03W

Sanwa Supply KB-SL7YS-03W Category 7 LAN Cable (Slim, Flexible, Anti-Snapping Connector, 3m, White)

▪️ This “soft LAN cable” features a flexible design that resists tangling.
▪️ A 10 Gigabit Ethernet-compatible LAN cable achieving 10Gbps transmission speed and 600MHz bandwidth.
▪️ Features a double-shielded structure: twisted pairs are shielded, and all four pairs are further shielded, effectively countering alien crosstalk noise.
▪️ Slim design with a 4.5mm cable diameter allows for easy handling and clean routing.
▪️ Features a polycarbonate connector with a U-shaped latch design to prevent clip breakage.
▪️ The absence of a latch cover enables smooth operation when inserting or removing the connector.
▪️ Integrated boot protects the cable core wires during bending.

■ Cable Length: 3m


■ Color: White


■ Connector Type: RJ-45 Shielded Connector


■ Slim Connector: Yes


■ Tab-Break Prevention Connector: Yes
U-shaped Latch Connector


■Shape Type: Ultra-Slim Type


■Cable Construction: ScTP


■Cable Conductor: 32AWG


■Cable Conductor Construction: Stranded Wire


■Wiring Specification: Straight Through Wiring


■Color Coding: TIA/EIA-568B


■Cable Diameter: 4.5mm


■Category: CAT7


■Standard Name: 10GBASE-T


■Supported Categories/Standards: Category 7 (10GBASE-T), Category 6A (10GBASE-T), Category 6 (1000BASE-TX), Category 5e (1000BASE-T), Category 5 (100BASE-TX), Category 3 (10BASE-T) compliant


■Communication Speed: 10Gbps, 1Gbps, 100Mbps, 10Mbps


■Frequency Response: 600MHz


■Inspection: 100% continuity test


■Shape Specification Type: Ultra-thin cable


■Number of Cables: 8 cores (4P)


■Operating Temperature Range: -20~60℃
Brand Name: Sanwa Supply
This is a “Soft LAN Cable” that is flexible and resistant to tangling.
It is a 10 Gigabit Ethernet LAN cable achieving a transmission speed of 10Gbps and a transmission bandwidth of 600MHz.
Features a double-shielded structure: shielded twisted pairs, plus an additional shield around all 4 pairs, effectively countering alien crosstalk noise.
Slim design with a 4.5mm cable diameter allows for easy handling and clean, tidy wiring.
Features polycarbonate connectors with a U-shaped latch design to prevent connector clip breakage.
4969887770863
Sanwa Supply Category 7 LAN Cable (Slim, Flexible, Anti-Snap Connector, 3m・White) KB-SL7YS-03W
(text created at , 2025-05-09)

195x20x240 mm

80 g
