Sanwa Supply Optical Media Converter (Gigabit Compatible, Bridge, Multimode) LAN-EC212CB
JAN
4969887773956
ASIN
B0FCXQ1SVD
Maker
Model No.
LAN-EC212CB
Color
Size
Description
Sanwa Supply-Sanwa-Supply-LAN-EC212CB-Optical Media Converter (Gigabit Compatible, Bridge, Multimode)
▪️This switch-type (bridge-type) optical media converter features an RJ-45 port (for metal cables) and an SC port (for fiber optic cables), enabling the integration of 10BASE-T/100BASE-TX/1000BASE-T into 1000BASE-SX.\
▪️Extends networks at Gigabit speeds up to 550m without any noise interference.\
▪️RJ-45 port features auto-negotiation, full duplex support, flow control, and Auto-MDI/MDI-X.\
▪️Includes LLF (Link Loss Forwarding) and LFP (Link Fault Pass-Through) functions.\
▪️ Supports jumbo frames.\
■ Connector Configuration: RJ-45 Connector ×1 - SC Connector ×2\
SC Connector (Duplex) Supported\
■Interface Standards: IEEE 802.3 (10BASE-T), IEEE 802.3u (100BASE-TX), IEEE 802.3ab (1000BASE-T), IEEE 802.3z (1000BASE-X), IEEE 802.3x (Flow Control)\
■Dimensions: W75 × D101.5 × H22.5 mm\
■Weight: 206 g\
■Standards: IEEE802.3 10BASE-T\
IEEE802.3ab 1000BASE-T\
IEEE802.3u 100BASE-TX\
IEEE 802.3z 1000BASE-X\
IEEE802.3x Flow Control\
■Type: Switch Type (Bridge Type)\
■Connectors: RJ-45 Port ×1\
SC Connector Port ×2\
■Compatible Cables: Category 5e or higher LAN cable (1000BASE-T)\
50/125μm, 62.5/125μm multimode fiber optic cable (1000BASE-SX)\
■Data Transfer Rate: 1000Mbps/Full Duplex\
■Packet Transfer Capacity: 1,488,000 pps / 1000Mbps\
■Maximum Frame Length: 9.6K\
■Optical Fiber Specifications: Mode / Multimode\
Transmission Speed / 1000Mbps\
Transmission Method / Full-duplex\
Maximum Transmission Distance / Maximum Extension 550m / 50μ, 220m / 62.5μ (MM850nm)\
Minimum TX Power/-9.5dB\
Maximum TX Power/-4dBm\
Maximum RX Sensitivity/-18dBm\
Power Budget/8.5dBm\
■Dimensions: W75×D101.5×H22.5mm\
■Weight: 206g\
■Operating Environment:\
Temperature Range/0 to 50°C\
Humidity Range/10 to 90%\
■Accessories: AC Adapter (DC5V/2A)\
■Certifications: FCC Class A, CE Class A
Brand Name: Sanwa Supply
AC Adapter (DC5V/2A)\ nThis switch-type (bridge-type) optical media converter features an RJ-45 port (for metal cables) and an SC port (for fiber optic cables), enabling the integration of 10BASE-T/100BASE-TX/1000BASE-T into 1000BASE-SX.
It can extend networks at Gigabit speeds up to 550m without any noise interference.
RJ-45 port
▪️This switch-type (bridge-type) optical media converter features an RJ-45 port (for metal cables) and an SC port (for fiber optic cables), enabling the integration of 10BASE-T/100BASE-TX/1000BASE-T into 1000BASE-SX.\
▪️Extends networks at Gigabit speeds up to 550m without any noise interference.\
▪️RJ-45 port features auto-negotiation, full duplex support, flow control, and Auto-MDI/MDI-X.\
▪️Includes LLF (Link Loss Forwarding) and LFP (Link Fault Pass-Through) functions.\
▪️ Supports jumbo frames.\
■ Connector Configuration: RJ-45 Connector ×1 - SC Connector ×2\
SC Connector (Duplex) Supported\
■Interface Standards: IEEE 802.3 (10BASE-T), IEEE 802.3u (100BASE-TX), IEEE 802.3ab (1000BASE-T), IEEE 802.3z (1000BASE-X), IEEE 802.3x (Flow Control)\
■Dimensions: W75 × D101.5 × H22.5 mm\
■Weight: 206 g\
■Standards: IEEE802.3 10BASE-T\
IEEE802.3ab 1000BASE-T\
IEEE802.3u 100BASE-TX\
IEEE 802.3z 1000BASE-X\
IEEE802.3x Flow Control\
■Type: Switch Type (Bridge Type)\
■Connectors: RJ-45 Port ×1\
SC Connector Port ×2\
■Compatible Cables: Category 5e or higher LAN cable (1000BASE-T)\
50/125μm, 62.5/125μm multimode fiber optic cable (1000BASE-SX)\
■Data Transfer Rate: 1000Mbps/Full Duplex\
■Packet Transfer Capacity: 1,488,000 pps / 1000Mbps\
■Maximum Frame Length: 9.6K\
■Optical Fiber Specifications: Mode / Multimode\
Transmission Speed / 1000Mbps\
Transmission Method / Full-duplex\
Maximum Transmission Distance / Maximum Extension 550m / 50μ, 220m / 62.5μ (MM850nm)\
Minimum TX Power/-9.5dB\
Maximum TX Power/-4dBm\
Maximum RX Sensitivity/-18dBm\
Power Budget/8.5dBm\
■Dimensions: W75×D101.5×H22.5mm\
■Weight: 206g\
■Operating Environment:\
Temperature Range/0 to 50°C\
Humidity Range/10 to 90%\
■Accessories: AC Adapter (DC5V/2A)\
■Certifications: FCC Class A, CE Class A
Brand Name: Sanwa Supply
AC Adapter (DC5V/2A)\ nThis switch-type (bridge-type) optical media converter features an RJ-45 port (for metal cables) and an SC port (for fiber optic cables), enabling the integration of 10BASE-T/100BASE-TX/1000BASE-T into 1000BASE-SX.
It can extend networks at Gigabit speeds up to 550m without any noise interference.
RJ-45 port
Package
Size (Approx.):
Size (Approx.):
165x55x215 mm
Package
Weight (Approx.):
Weight (Approx.):
430 g
51,370 JPY (Including Tax)
Stock :
5
Scheduled Shipping:
2026-02-12
