Sanwa Supply USB Type-C to HDMI Adapter 4K/60Hz/HDR Simple Packaging Version Black AD-ALCHDR04TK
JAN
4969887774045
ASIN
B0FB3N7J55
Maker
Model No.
AD-ALCHDR04TK
Color
Size
Description
Sanwa Supply - Type-C to HDMI Conversion Adapter (4K-HDR, Simplified Packaging Version) - AD-ALCHDR04TK
▪️ Outputs video and audio from computers or tablets equipped with USB Type-C (only Type-C ports supporting video output) to displays or TVs with HDMI input terminals.
▪️Supports DisplayPort Alternate Mode for adding displays via USB Type-C connection, enabling easy setup of multi-display environments (Mirror Mode/Extended Mode) without software installation.
▪️Supports 4K (3840×2160)/60Hz resolution, outputting beautiful, high-definition HDMI signals.
▪️ Supports high-brightness HDR (High Dynamic Range) video and is compatible with HDCP 1.4/2.2/2.3.
▪️ The 20cm cable length allows for easy connection and handling.
▪️ Comes in simple packaging. 【Please Confirm Before Purchase】 ※ Compatible with computers equipped with a USB Type-C port that supports DisplayPort Alternate Mode. ※Not compatible with Nintendo Switch™. 【 USB 】
■Interface Standard: USB 5Gbps compliant (USB3.2 Gen1/3.1 Gen1/3.0)
■Connector Type (PC Connection Side): USB Type-C
■Power: Bus-powered 【 Video Output Port 】
■Port Type: HDMI Type A (19-pin) Female
■Maximum Display Resolution: 4K/60Hz
■Supported Resolution: Maximum Display Resolution 4K/60Hz
※The PC, projector, display, and connection cable must all support the same resolution.
■HDR Support: Supported
■HDCP: HDCP1.4, HDCP2.2, HDCP2.3
【 Video Standard 】
■HDMI Standard: HDMI2.0
【 Common Specifications 】
■Current Consumption: Max 220mA
■Shielding Method: Triple Shielding
■Cable Length: 0.2m
■Cable Diameter: 4mm
■Dimensions: W41.8 × D38 × H15.5mm
Brand Name: Sanwa Supply
Connects computers or tablets equipped with USB Type-C (only Type-C ports supporting video output) to displays or TVs with HDMI input ports for video and audio output.
Supports DisplayPort Alternate Mode for USB Type-C display expansion, enabling easy setup of multi-display environments (Mirror Mode/Extended Mode) without software installation.
Supports 4K (3840×2160)/60Hz resolution for beautiful, high-definition HDMI signal output.
Supports high-brightness HDR (High Dynamic Range) video and is compatible with HDCP 1.4/2.2/2.3.
The 20cm cable length allows for easy connection and handling.
4969887774045
Sanwa Supply USB Type-C to HDMI Adapter 4K/60Hz/HDR Simple Packaging Version Black AD-ALCHDR04TK
(text created at , 2025-09-07)
▪️ Outputs video and audio from computers or tablets equipped with USB Type-C (only Type-C ports supporting video output) to displays or TVs with HDMI input terminals.
▪️Supports DisplayPort Alternate Mode for adding displays via USB Type-C connection, enabling easy setup of multi-display environments (Mirror Mode/Extended Mode) without software installation.
▪️Supports 4K (3840×2160)/60Hz resolution, outputting beautiful, high-definition HDMI signals.
▪️ Supports high-brightness HDR (High Dynamic Range) video and is compatible with HDCP 1.4/2.2/2.3.
▪️ The 20cm cable length allows for easy connection and handling.
▪️ Comes in simple packaging. 【Please Confirm Before Purchase】 ※ Compatible with computers equipped with a USB Type-C port that supports DisplayPort Alternate Mode. ※Not compatible with Nintendo Switch™. 【 USB 】
■Interface Standard: USB 5Gbps compliant (USB3.2 Gen1/3.1 Gen1/3.0)
■Connector Type (PC Connection Side): USB Type-C
■Power: Bus-powered 【 Video Output Port 】
■Port Type: HDMI Type A (19-pin) Female
■Maximum Display Resolution: 4K/60Hz
■Supported Resolution: Maximum Display Resolution 4K/60Hz
※The PC, projector, display, and connection cable must all support the same resolution.
■HDR Support: Supported
■HDCP: HDCP1.4, HDCP2.2, HDCP2.3
【 Video Standard 】
■HDMI Standard: HDMI2.0
【 Common Specifications 】
■Current Consumption: Max 220mA
■Shielding Method: Triple Shielding
■Cable Length: 0.2m
■Cable Diameter: 4mm
■Dimensions: W41.8 × D38 × H15.5mm
Brand Name: Sanwa Supply
Connects computers or tablets equipped with USB Type-C (only Type-C ports supporting video output) to displays or TVs with HDMI input ports for video and audio output.
Supports DisplayPort Alternate Mode for USB Type-C display expansion, enabling easy setup of multi-display environments (Mirror Mode/Extended Mode) without software installation.
Supports 4K (3840×2160)/60Hz resolution for beautiful, high-definition HDMI signal output.
Supports high-brightness HDR (High Dynamic Range) video and is compatible with HDCP 1.4/2.2/2.3.
The 20cm cable length allows for easy connection and handling.
4969887774045
Sanwa Supply USB Type-C to HDMI Adapter 4K/60Hz/HDR Simple Packaging Version Black AD-ALCHDR04TK
(text created at , 2025-09-07)
Package
Size (Approx.):
Size (Approx.):
107x14x176 mm
Package
Weight (Approx.):
Weight (Approx.):
30 g
3,150 JPY (Including Tax)
Stock :
5
Scheduled Shipping:
2026-02-12
Quantity :
Reference Price from Other Stores
