300V/5A Screwless Terminal Block (3P) EA940DM-73A
JAN
4548745247022
ASIN
B01BBDP0RC
Maker
Model No.
EA940DM-73A
Color
Size
26.62 (W) × 47.5 (D) × 14.7 (H) mm
Description
Brand Name: Esco
Rated: DC300V-5A
Insulation Resistance: DC500V, 100MΩ or more
Total Contact Resistance (Initial Value): 30mΩ or less
Certifications: UL Standard (Field Wiring Compatible) C-UL Standard・TUV Standard (IEC61984)
Poles: 3-pole
Primary Insulation Material (Button): Modified P.P.E. (UL94V-0)
Primary Insulation Material (Body): Nylon 66 (UL94V-0)
Rated Compatible Wire: Solid Wire: Diameter 0.8mm² (AWG20) Stranded wire: 0.5mm² (AWG20)
Usable wire range: Solid wire: Diameter 0.4/1.2mm (AWG26/
4548745247022
300V/5A Screwless Terminal Block (3P) EA940DM-73A
(text created at , 2025-05-10)
Rated: DC300V-5A
Insulation Resistance: DC500V, 100MΩ or more
Total Contact Resistance (Initial Value): 30mΩ or less
Certifications: UL Standard (Field Wiring Compatible) C-UL Standard・TUV Standard (IEC61984)
Poles: 3-pole
Primary Insulation Material (Button): Modified P.P.E. (UL94V-0)
Primary Insulation Material (Body): Nylon 66 (UL94V-0)
Rated Compatible Wire: Solid Wire: Diameter 0.8mm² (AWG20) Stranded wire: 0.5mm² (AWG20)
Usable wire range: Solid wire: Diameter 0.4/1.2mm (AWG26/
4548745247022
300V/5A Screwless Terminal Block (3P) EA940DM-73A
(text created at , 2025-05-10)
Package
Size (Approx.):
Size (Approx.):
150x150x150 mm
Package
Weight (Approx.):
Weight (Approx.):
500 g
1,588 JPY (Including Tax)
Stock :
21
Scheduled Shipping:
2026-07-13
Quantity :
Reference Price from Other Stores
