ESCO Rc3/4 Needle Valve (Stainless Steel) EA470CN-6
JAN
4548745597769
ASIN
B006Y4ACKE
Maker
Model No.
EA470CN-6
Color
Size
d: Rc3/4, H: 104, D1: 85, L: 70, I: 8, D2: 10, D3: 25, h: 26, h1: 20.5, L1: 19, L2: 27, D4: M5
Description
Material: Body: SUS316, Stem: SUS630, Gasket: SUS316, Gasket Packing: PTFE+PFA, Panel Gasket: Non-asbestos Sheet, Set Screw: SUS304, Front Ferrule: SUS316, Back Ferrule: SUS316, Handle: ZDC Service Fluid: Air, Water, Oil, Gas, Chemicals Maximum Pressure: -20°C/ Ambient: 25.5MPa, Below 100°C: 21.77MPa, Below 150°C: 19.81MPa Panel tap provided at bottom of body for direct panel mounting Mounting Screw (PT): 3/4" Dimensions (mm): d: Rc3/4, H: 104, D1: 85, L:70, I:8, D2:10, D3:25, h:26, h1:20.5, L1:19, L2:27, D4:M5 Weight: 0.9kg
Brand Name: Esco
Material: Body: SUS316
Material: Body: SUS316, Stem: SUS630, Gland: SUS316, Gland Packing: PTFE+PFA, Panel Gasket: Non-asbestos Sheet, Set Screw: SUS304, Front Ferrule: SUS316, Back Ferrule: SUS316, Handle: ZDC
Service Fluid: Air, Water, Oil, Gas, Chemicals
Maximum Pressure: -20℃/ Ambient: 25.5MPa, Below 100°C: 21.77MPa, Below 150°C: 19.81MPa
Panel tap provided at bottom of body for direct panel mounting
Mounting Screw (PT): 3/4"
Dimensions (mm): d: Rc3/4, H: 104, D1: 85, L:70, I:8, D2:10, D3:25, h:26, h1:20.5, L1:19, L2:27, D4:M5
Weight:0.9kg
4548745597769\ nB006Y4ACKE
ESCO Rc3/4 Needle Valve (Stainless Steel) EA470CN-6
(text created at , 2025-11-12)
Brand Name: Esco
Material: Body: SUS316
Material: Body: SUS316, Stem: SUS630, Gland: SUS316, Gland Packing: PTFE+PFA, Panel Gasket: Non-asbestos Sheet, Set Screw: SUS304, Front Ferrule: SUS316, Back Ferrule: SUS316, Handle: ZDC
Service Fluid: Air, Water, Oil, Gas, Chemicals
Maximum Pressure: -20℃/ Ambient: 25.5MPa, Below 100°C: 21.77MPa, Below 150°C: 19.81MPa
Panel tap provided at bottom of body for direct panel mounting
Mounting Screw (PT): 3/4"
Dimensions (mm): d: Rc3/4, H: 104, D1: 85, L:70, I:8, D2:10, D3:25, h:26, h1:20.5, L1:19, L2:27, D4:M5
Weight:0.9kg
4548745597769\ nB006Y4ACKE
ESCO Rc3/4 Needle Valve (Stainless Steel) EA470CN-6
(text created at , 2025-11-12)
Package
Size (Approx.):
Size (Approx.):
250x100x250 mm
Package
Weight (Approx.):
Weight (Approx.):
2000 g
57,637 JPY (Including Tax)
Stock :
1
Scheduled Shipping:
2026-07-14
