G1/4 Male Thread Hose Stem (Stainless Steel)
JAN
4548745729320
ASIN
B00AXUKM00
Maker
Model No.
EA462EC-12
Color
Size
G (PF) 1-1/4"
Description
Material: Stainless Steel (SUS316)
Operating Temperature: -40°C/95°C
Pressure Rating: 2.5MPa (25kgf/cm2)
Electropolished Finish
Safety Flange
Compatible Clamp: EA462EE-12
Thread Size: G(PF) 1-1/4"\ Compatible hose inner diameter: 32mm
Hexagon diameter: 46mm
Overall height: 63.5mm
Weight: Approx. 210g
Brand name: Esco
Material: Stainless steel (SUS316)
Operating temperature: -40°C/95°C
Pressure Rating: 2.5MPa (25kgf/cm²)
Thread Size: G(PF) 1-1/4"
Compatible Hose ID: 32mm
Hexagon Flange Diameter: 46mm
Overall Height: 63.5mm
4548745729320
“G1-1/4” Male Thread Hose Stem (Stainless Steel)
(text created at , 2025-05-11)
Operating Temperature: -40°C/95°C
Pressure Rating: 2.5MPa (25kgf/cm2)
Electropolished Finish
Safety Flange
Compatible Clamp: EA462EE-12
Thread Size: G(PF) 1-1/4"\ Compatible hose inner diameter: 32mm
Hexagon diameter: 46mm
Overall height: 63.5mm
Weight: Approx. 210g
Brand name: Esco
Material: Stainless steel (SUS316)
Operating temperature: -40°C/95°C
Pressure Rating: 2.5MPa (25kgf/cm²)
Thread Size: G(PF) 1-1/4"
Compatible Hose ID: 32mm
Hexagon Flange Diameter: 46mm
Overall Height: 63.5mm
4548745729320
“G1-1/4” Male Thread Hose Stem (Stainless Steel)
(text created at , 2025-05-11)
Package
Size (Approx.):
Size (Approx.):
250x100x250 mm
Package
Weight (Approx.):
Weight (Approx.):
2000 g
4,450 JPY (Including Tax)
