2.5 Ton/M20x31mm Multi-Eye Bolt EA987GY-20
JAN
4548745822496
ASIN
B00AXVDLZC
Maker
Model No.
EA987GY-20
Color
Size
83 × 135 mm
Description
ESCO-ESCO-2-5ton-M20x31mm-Multi Eye Bolt EA987GY-20 Features Ministry of Land, Infrastructure, Transport and Tourism New Technology Provision System ‘NETIS’ Certified Product NETIS Registration Number/KK-150017-VE n360-degree rotation relative to the heavy-load lifting axis\
180-degree movement relative to the lifting direction\
Enables safe use during lateral lifting, diagonal lifting, and hoisting operations—tasks that posed risks with conventional JIS eye bolts.\
Supports three times the working load of JIS eye bolts, allowing smaller threaded holes in the load object and reducing costs. \
\
Specifications\
Manufacturer: Naniwa Iron Works (IRON WAVE)\
Model: ME2018C\
Working Load: 2.5t\
Screw Size: M20×31\
Internal Dimensions: 47×60mm\
Ring Size: 83×135mm\
Ring Wire Diameter: 18mm\\ nApproximate Tightening Torque: 7.0~15.0 kgf·m\
Material: Forged Iron Core/SCM (Chromium-Molybdenum Steel)\
Weight: 1.38 kg
Brand Name: Esco\
Material: Forged iron core/SCM (Chromium-Molybdenum Steel)
Quantity: 1 piece
Screw Size: M20×31
4548745822496\ B00AXVDLZC
2.5ton/M20x31mm Multi-Eye Bolt EA987GY-20
(text created at , 2025-11-12)
180-degree movement relative to the lifting direction\
Enables safe use during lateral lifting, diagonal lifting, and hoisting operations—tasks that posed risks with conventional JIS eye bolts.\
Supports three times the working load of JIS eye bolts, allowing smaller threaded holes in the load object and reducing costs. \
\
Specifications\
Manufacturer: Naniwa Iron Works (IRON WAVE)\
Model: ME2018C\
Working Load: 2.5t\
Screw Size: M20×31\
Internal Dimensions: 47×60mm\
Ring Size: 83×135mm\
Ring Wire Diameter: 18mm\\ nApproximate Tightening Torque: 7.0~15.0 kgf·m\
Material: Forged Iron Core/SCM (Chromium-Molybdenum Steel)\
Weight: 1.38 kg
Brand Name: Esco\
Material: Forged iron core/SCM (Chromium-Molybdenum Steel)
Quantity: 1 piece
Screw Size: M20×31
4548745822496\ B00AXVDLZC
2.5ton/M20x31mm Multi-Eye Bolt EA987GY-20
(text created at , 2025-11-12)
Package
Size (Approx.):
Size (Approx.):
131x64x164 mm
Package
Weight (Approx.):
Weight (Approx.):
1510 g
21,967 JPY (Including Tax)
Stock :
2
Scheduled Shipping:
2026-07-14
Quantity :
Reference Price from Other Stores
