2-pole [DC300V/10A] screwless terminal block 26.62(W) × 50.5(D) × 16.0(H) mm
JAN
4548745864557
ASIN
B01N9X27AK
Maker
Model No.
EA940DM-102A
Color
Size
26.62 (W) × 50.5 (D) × 16.0 (H) mm
Description
Rated: DC300V-10A
Withstand Voltage: AC2000V (1 minute)
Insulation Resistance: DC500V, 100MΩ or more
Total Contact Resistance (Initial Value): 30mΩ or less
Certifications: UL Standard (Field Wiring Compliant) C-UL Standard・TUV Standard (IEC61984)
Poles: 2P
Primary Insulation Material: Nylon 66 (UL94V-0)
Primary Insulation Material (Button): Modified P.P.E. (UL94V-0)
Rated Compatible Wire: Solid Wire: Diameter 1.2mm (AWG16) Stranded Wire: 1.25mm² (AWG16)
Brand Name: Esco
Rated: DC300V-10A
Withstand Voltage: AC2000V (1 minute)
Insulation Resistance: DC500V, 100MΩ or more
Total Contact Resistance (Initial Value): 30mΩ or less
Certifications: UL Standard (Field Wiring Compatible) C-UL Standard・TUV Standard (IEC61984)
Poles: 2P
Primary Insulation Material: Nylon 66 (UL94V-0)
Primary Insulation Material (Button): Modified P.P.E. (UL94V-0)
Rated Compatible Wire: Solid Wire: Diameter 1.2mm (AWG16) Stranded Wire: 1.25mm² (AWG16)
4548745864557
2-Pole [DC300V/10A] Screwless Terminal Block 26.62(W)×50.5(D)×16.0(H)mm
(text created at , 2025-05-09)
Withstand Voltage: AC2000V (1 minute)
Insulation Resistance: DC500V, 100MΩ or more
Total Contact Resistance (Initial Value): 30mΩ or less
Certifications: UL Standard (Field Wiring Compliant) C-UL Standard・TUV Standard (IEC61984)
Poles: 2P
Primary Insulation Material: Nylon 66 (UL94V-0)
Primary Insulation Material (Button): Modified P.P.E. (UL94V-0)
Rated Compatible Wire: Solid Wire: Diameter 1.2mm (AWG16) Stranded Wire: 1.25mm² (AWG16)
Brand Name: Esco
Rated: DC300V-10A
Withstand Voltage: AC2000V (1 minute)
Insulation Resistance: DC500V, 100MΩ or more
Total Contact Resistance (Initial Value): 30mΩ or less
Certifications: UL Standard (Field Wiring Compatible) C-UL Standard・TUV Standard (IEC61984)
Poles: 2P
Primary Insulation Material: Nylon 66 (UL94V-0)
Primary Insulation Material (Button): Modified P.P.E. (UL94V-0)
Rated Compatible Wire: Solid Wire: Diameter 1.2mm (AWG16) Stranded Wire: 1.25mm² (AWG16)
4548745864557
2-Pole [DC300V/10A] Screwless Terminal Block 26.62(W)×50.5(D)×16.0(H)mm
(text created at , 2025-05-09)
Package
Size (Approx.):
Size (Approx.):
300x200x300 mm
Package
Weight (Approx.):
Weight (Approx.):
1000 g
1,423 JPY (Including Tax)
