3-pole [DC300V/10A] Screwless Terminal Block 31.70(W) × 50.5(D) × 16.0(H) mm
JAN
4548745864564
ASIN
B07CJ7ZLB4
Maker
Model No.
EA940DM-103A
Color
Size
31.70 (W) × 50.5 (D) × 16.0 (H) mm
Description
Poles: 3P, Certifications: UL Standard (Field Wiring Compliant), C-UL Standard, TUV Standard (IEC61984), Standard Stripped Wire Length: 10mm, RoHS Compliant
Rated: DC300V-10A, Primary Insulation Material: Nylon 66 (UL94V-0), Size: A: 31.7mm B: 17.5mm Height: 50.5mm
Withstand Voltage: AC2000V (1 minute), Primary Insulation Material (Button): Modified P.P.E. (UL94V-0), Terminal pitch: 5.08mm
Insulation resistance: DC500V, 100MΩ or more, Rated compatible wire: Solid wire: φ1.2mm (AWG16) Stranded wire: 1.25mm² (AWG16), 2-piece terminal block
Total contact resistance (initial value): 30mΩ or less, Applicable wire range: Solid wire: φ0.4mm~1.6mm (AWG26~14) Stranded wire: 0.2mm²~2.0mm² (AWG24~14) Strand diameter φ0.18mm or larger, Button lock mechanism
Brand Name: Esco
Poles: 3P, Certifications: UL Standard (Field Wiring Compliant), C-UL Standard, TUV Standard (IEC61984), Standard Stripping Length: 10mm, RoHS Compliant
Rated: DC300V-10A, Primary Insulation Material: Nylon 66 (UL94V-0), Size: A: 31.7mm B: 17.5mm Height: 50.5mm
Withstand Voltage: AC2000V (1 minute), Primary Insulation Material (Button): Modified P.P.E. (UL94V-0), Terminal pitch: 5.08mm
Insulation resistance: DC500V, 100MΩ or more, Rated compatible wire: Solid wire: φ1.2mm (AWG16) Stranded wire: 1.25mm² (AWG16), 2-piece terminal block
Total contact resistance (initial value): 30mΩ or less, Applicable wire range: Solid wire: φ0.4mm~1.6mm (AWG26~14) Stranded wire: 0.2mm²~2.0mm² (AWG24~14) Strand diameter φ0.18mm or larger, Button lock mechanism
4548745864564
3-pole [DC300V/10A] Screwless Terminal Block 31.70(W)×50.5(D)×16.0(H)mm
(text created at , 2025-05-11)
Rated: DC300V-10A, Primary Insulation Material: Nylon 66 (UL94V-0), Size: A: 31.7mm B: 17.5mm Height: 50.5mm
Withstand Voltage: AC2000V (1 minute), Primary Insulation Material (Button): Modified P.P.E. (UL94V-0), Terminal pitch: 5.08mm
Insulation resistance: DC500V, 100MΩ or more, Rated compatible wire: Solid wire: φ1.2mm (AWG16) Stranded wire: 1.25mm² (AWG16), 2-piece terminal block
Total contact resistance (initial value): 30mΩ or less, Applicable wire range: Solid wire: φ0.4mm~1.6mm (AWG26~14) Stranded wire: 0.2mm²~2.0mm² (AWG24~14) Strand diameter φ0.18mm or larger, Button lock mechanism
Brand Name: Esco
Poles: 3P, Certifications: UL Standard (Field Wiring Compliant), C-UL Standard, TUV Standard (IEC61984), Standard Stripping Length: 10mm, RoHS Compliant
Rated: DC300V-10A, Primary Insulation Material: Nylon 66 (UL94V-0), Size: A: 31.7mm B: 17.5mm Height: 50.5mm
Withstand Voltage: AC2000V (1 minute), Primary Insulation Material (Button): Modified P.P.E. (UL94V-0), Terminal pitch: 5.08mm
Insulation resistance: DC500V, 100MΩ or more, Rated compatible wire: Solid wire: φ1.2mm (AWG16) Stranded wire: 1.25mm² (AWG16), 2-piece terminal block
Total contact resistance (initial value): 30mΩ or less, Applicable wire range: Solid wire: φ0.4mm~1.6mm (AWG26~14) Stranded wire: 0.2mm²~2.0mm² (AWG24~14) Strand diameter φ0.18mm or larger, Button lock mechanism
4548745864564
3-pole [DC300V/10A] Screwless Terminal Block 31.70(W)×50.5(D)×16.0(H)mm
(text created at , 2025-05-11)
Package
Size (Approx.):
Size (Approx.):
52x10x120 mm
Package
Weight (Approx.):
Weight (Approx.):
16 g
2,005 JPY (Including Tax)
Stock :
17
Scheduled Shipping:
2026-07-13
Quantity :
