ELECOM LAN Cable Standard Type CAT6 Compatible Clip-Resistant Type Eco-Friendly Packaging [...] LD-GPT/LG50/RS

4549550164221

B088D7151M

LD-GPT/LG50/RS

ELECOM - RoHS Directive Compliant - LD-GPT-LG50-RS
\


■Color: Light Gray\


■Interface: RJ-45 Connector\


■Environmental Considerations: Compliant with EU RoHS Directive (10 Substances)\


■Specification: Cat6 compliant (supports 10BASE-T/100BASE-TX/1000BASE-T/1000BASE-TX)\


■Transmission Speed: 1Gbps\


■Transmission Bandwidth: 250MHz\


■Cable Length: Approx. 50m (excluding connectors)\


■Cable Diameter: Approx. 5.5mm\


■Number of Cores: 8 cores\


■Wiring Method: Straight wiring\


■Twisted Pair Cable: Yes\


■Cross-shaped Spacer: No\


■Outer Sheath (Jacket) Material: PVC\


■Length Markings: No\


■Conductor Construction: Stranded\


■Connector Presence: Connectors on Both Ends\


■Molded Connector: Yes\


■Slim Connector: Yes\


■Connector with Clip Breakage Prevention Cover: Yes\


■Cable Retraction Function: No\


■Package Type: Poly Bag (Environmentally Considerate Type)\


■Connector with Clip Breakage Prevention: Yes\\ n

■PoE: Yes\


■This is a standard type Cat6 compliant LAN cable.\


■Features a double-layered structure with a claw-break prevention protector and connectors made from highly durable material resistant to bending, making it a LAN cable less prone to claw breakage. ※Passed 1000 bend tests (verified by our company)\


■Prevents cable disconnection due to clip breakage, ensuring secure, long-term fixation in LAN ports.\


■Enables stable networking in 1000BASE-TX and 1000BASE-T environments.\


■Guarantees a 250MHz frequency bandwidth, suitable for high-speed Gigabit Ethernet communication.\


■Features a twisted pair design without cross-interference, making it flexible and easy to handle, even in tight spaces.\


■Employs a slim connector that minimizes protrusion and avoids interference with adjacent ports.\


■Meets flame resistance standards by passing the 60-degree tilt test (JIS C 3005).\


■Environmentally friendly product compliant with the EU's RoHS Directive (Restriction of Hazardous Substances in Electrical and Electronic Equipment) for 10 substances.\


■Product packaging consists solely of paper, cardboard, and polyethylene bags.\
ELECOM General Information Center\
TEL. 0570-084-465\
FAX. 0570-050-012\
Hours: 10:00 AM - 7:00 PM, Open Year-Round\
Brand Name: ELECOM\
Unit Only\
This standard Cat6 compliant LAN cable supports Gigabit Ethernet, guaranteeing a 250MHz frequency bandwidth. Features a double-layered structure with a protector and a highly durable connector, making it resistant to clip breakage. ※Passed 1000 bend tests (in-house verification)
This is a standard type Cat6 compliant LAN cable.
Features a double-layered structure with a clip breakage prevention protector and a connector made of highly durable material resistant to bending, making it a LAN cable resistant to clip breakage.

250x55x250 mm

1566 g
