ESCO [50V/3A] Screwless Terminal Block for PCB/White 2-Pole EA940DM-202

4550061097014

B0BWR7NQQX

EA940DM-202

15.6 × 13.5 mm

▪️Poles: 2-pole
▪️Size (Width): 6.58mm
▪️Rated: 50V-3A
▪️Acceptable Wire: Solid wire ／ φ0.32~0.65mm Stranded wire ／ 0.08~0.32mm² (Single wire diameter φ0.12mm or larger)

▪️Dimensions (Depth × Height): 15.65 × 13.5mm
▪️Material: Body／Nylon 66 (UL94V-0) Button／Modified PPE (UL94V-0)
▪️Insulation Resistance: DC500V, 50MΩ or higher
▪️Withstand Voltage: AC1500V (1 minute)
▪️Certifications: UL Standard (Field Wiring Compliant)・CSA Standard・TÜV Standard (Compliant with IEC60947-7-1)
▪️Standard Stripping Length: 9~10mm
▪️Recommended Tool: Flathead Screwdriver (Shaft Diameter φ3mm, Blade Width 2.6mm)
▪️ Terminal Type: PC Terminal
▪️ Terminal Pitch: 2.54mm
▪️ Button Color: White
▪️ Inspection Hole: Yes
▪️ For PCB Use
※※For Business Use Only※※
Brand Name: Esco
Poles: 2-Pole
Size (Width): 6.58mm
Rated: 50V-3A
Acceptable Wire: Solid wire / φ0.32–0.65mm Stranded wire / 0.08–0.32mm² (single strand diameter φ0.12mm or larger)
Size (Depth × Height): 15.65 × 13.5mm
Material: Body / Nylon 66 (UL94V-0) Button / Modified PPE (UL94V-0)
Insulation resistance: DC500V, 50MΩ or higher
Withstand voltage: AC1500V (1 minute)
Certifications: UL standard (Field Wiring compliant)・CSA standard・TUV standard (Compliant with IEC60947-7-1)
Standard wire stripping length: 9 to 10mm
4550061097014
ESCO [50V/3A] Screwless Terminal Block for PCB/White 2-Pole EA940DM-202
