18-pole [50V/3A] Screwless Terminal Block (PCB Mount / White) 10×15.65mm
JAN
4550061098653
ASIN
B0BWR5R2PW
Maker
Model No.
EA940DM-238
Color
Size
10 × 15.65 mm
Description
Brand Name: Esco
Poles: 18-pole
Size (Width): 47.22mm
Rated: 50V-3A
Acceptable Wire: Solid Wire / φ0.32–0.65mm Stranded Wire / 0.08–0.32mm² (Single Wire Diameter φ0.12mm or larger)
Size (Depth × Height): 10 × 15.65mm
Material: Body / Nylon 66 (UL94V-0) Button / Modified PPE (UL94V-0)
Insulation resistance: DC500V, 50MΩ or higher
Withstand voltage: AC1500V (1 minute)
Certifications: UL standard (Field Wiring compliant)・CSA standard・TUV standard (Compliant with IEC60947-7-1)
Standard wire stripping length: 9 to 10mm
4550061098653
18-pole [50V/3A] Screwless Terminal Block (PCB Mount / White) 10×15.65mm
(text created at , 2025-05-13)
Poles: 18-pole
Size (Width): 47.22mm
Rated: 50V-3A
Acceptable Wire: Solid Wire / φ0.32–0.65mm Stranded Wire / 0.08–0.32mm² (Single Wire Diameter φ0.12mm or larger)
Size (Depth × Height): 10 × 15.65mm
Material: Body / Nylon 66 (UL94V-0) Button / Modified PPE (UL94V-0)
Insulation resistance: DC500V, 50MΩ or higher
Withstand voltage: AC1500V (1 minute)
Certifications: UL standard (Field Wiring compliant)・CSA standard・TUV standard (Compliant with IEC60947-7-1)
Standard wire stripping length: 9 to 10mm
4550061098653
18-pole [50V/3A] Screwless Terminal Block (PCB Mount / White) 10×15.65mm
(text created at , 2025-05-13)
Package
Size (Approx.):
Size (Approx.):
- mm
Package
Weight (Approx.):
Weight (Approx.):
- g
1,313 JPY (Including Tax)
Stock :
25
Scheduled Shipping:
2026-07-13
Quantity :
