ESCO Rc1·1/4 Three-Way Ball Valve Vertical Type/Brass EA470BA-312
JAN
4550061559246
ASIN
B092QVFRPN
Maker
Model No.
EA470BA-312
Color
Size
L: 89, H: 60, D: 130, L1: 44.5
Description
▪️Material…Valve body: Forged brass (C3771) Cover: Forged brass (C3771) Valve stem: Brass (C3531(13)) Ball: Forged brass (C3771(1))\
▪️Maximum Pressure (Water/Oil/Gas(※))…Below 38°C: 2.75MPa Below 150°C: 0.69MPa\
▪️※Caution…Not for use with flammable or toxic gases\
▪️Operating Temperature Range…-20°C to 150°C\
▪️Vertical Type\
▪️Thread Size…Rc1-1/4”\\
▪️Dimensions (mm)…L: 89, H: 60, D: 130\
▪️Weight…1.0kg
Brand Name: Esco
Material…Valve body: Forged brass (C3771) Cover: Forged brass (C3771) Valve stem: Brass (C3531(13)) Ball: Forged Brass (C3771(1))
Maximum Pressure (Water/Oil/Gas(※))… Below 38°C: 2.75MPa Below 150°C: 0.69MPa
※Caution…Not for use with flammable or toxic gases
Operating Temperature Range…-20°C to 150°C
Vertical Type
4550061559246\ nB092QVFRPN
ESCO Rc1･1/4 Three-Way Ball Valve Vertical Type/Brass EA470BA-312
(text created at , 2025-11-12)
▪️Maximum Pressure (Water/Oil/Gas(※))…Below 38°C: 2.75MPa Below 150°C: 0.69MPa\
▪️※Caution…Not for use with flammable or toxic gases\
▪️Operating Temperature Range…-20°C to 150°C\
▪️Vertical Type\
▪️Thread Size…Rc1-1/4”\\
▪️Dimensions (mm)…L: 89, H: 60, D: 130\
▪️Weight…1.0kg
Brand Name: Esco
Material…Valve body: Forged brass (C3771) Cover: Forged brass (C3771) Valve stem: Brass (C3531(13)) Ball: Forged Brass (C3771(1))
Maximum Pressure (Water/Oil/Gas(※))… Below 38°C: 2.75MPa Below 150°C: 0.69MPa
※Caution…Not for use with flammable or toxic gases
Operating Temperature Range…-20°C to 150°C
Vertical Type
4550061559246\ nB092QVFRPN
ESCO Rc1･1/4 Three-Way Ball Valve Vertical Type/Brass EA470BA-312
(text created at , 2025-11-12)
Package
Size (Approx.):
Size (Approx.):
- mm
Package
Weight (Approx.):
Weight (Approx.):
- g
41,898 JPY (Including Tax)
Stock :
1
Scheduled Shipping:
2026-07-13
Quantity :
Reference Price from Other Stores
