Esco Flexible Pipe Elbow Connector φ28mm EA947HN-23J

4550061710074

B09SHC7R2N

EA947HN-23J

φ44 × 71.2 mm

Esco Flexible Pipe Elbow Connector - φ28mm - EA947HN-23J

▪️ Compatible Pipe Size (Standard)…PFS28
▪️ Compatible Pipes…EA947HN-29, 30
▪️ Compatible Knockout Diameter…φ34mm
▪️ Thread Size (G)…1”
▪️Material…Flame-retardant ABS
▪️Color…Beige
▪️Dimensions…φD1: 47mm, φD2: 44mm, L1: 71.2mm, L2: 14mm
▪️45°
▪️G Type
▪️JIS C8412
▪️Compatible with Mira Flex SS/SD
▪️Installation and removal in one simple step
▪️Convenient for piping to side knockouts when the box position is low, or for routing around rebar.
▪️Can be made waterproof by using the waterproof gasket set (EA947HN-23K). ※For PF pipes, use Milano Flex SS (EA947HN-29, 30).
Brand Name: Esco
Compatible Pipe Size (Standard)…PFS28
JIS C8412
Compatible Pipes…EA947HN-29, 30
Compatible Knockout Diameter…φ34mm
Thread Size (G)...1"
Material...Flame-retardant ABS
Color...Beige
Dimensions...φD1: 47mm, φD2: 44mm, L1: 71.2mm, L2: 14mm
45°
G Type
4550061710074
Esco Flexible Pipe Elbow Connector φ28mm EA947HN-23J
