Esco 10mm/0.01/58mm Dial Gauge EA725MA-22
JAN
4550061775004
ASIN
B09S5T9YN3
Maker
Model No.
EA725MA-22
Color
Size
Description
▪️Scale (mm)…0.01▪️Measuring range (mm)…0~10▪️Scale specification…±0~100▪️Dial diameter (mm)…58▪️Overall length (mm)…112▪️Mounting shaft diameter…φ8mm▪️Probe length…21mm▪️ Material…Body: Steel Probe tip: Super-hard
▪️ Return error…3μm
▪️ Measuring force…1.5N or less
▪️ Long needle 1 revolution…1mm
▪️ Adjacent error per 1/10 revolution…10μm▪️Indicating error over full range…±20μm▪️Repeatability…3μm▪️Weight…190g▪️Accessories…Two types of back covers (flat type, flanged type)▪️For measuring surface irregularities, workpiece mounting quality, shaft runout, perpendicularity, and other displacements.
▪️The most common dial gauge with a scale division of 0.01mm.▪️Equipped with a limit needle.▪️Uses jewel bearings in the bearing section.▪️Scale plate is green.▪️Two types of back covers included: flat type and type with lugs.▪️Shockproof mechanism protects the gears from sudden upward pressure on the spindle.
Brand Name: Esco
Scale (mm)...0.01
Measuring Force...1.5N or less
Measuring Range (mm)...0 to 10
Scale Specification...±0 to 100
Dial Diameter (mm)...58
Overall Length (mm)...112
Mounting Shaft Diameter...φ8mm
Probe Length...21mm
Material…Body: Steel Probe Tip: Carbide
Return Error…3μm
4550061775004
Esco 10mm/0.01/58mm Dial Gauge EA725MA-22
(text created at , 2025-05-10)
▪️ Return error…3μm
▪️ Measuring force…1.5N or less
▪️ Long needle 1 revolution…1mm
▪️ Adjacent error per 1/10 revolution…10μm▪️Indicating error over full range…±20μm▪️Repeatability…3μm▪️Weight…190g▪️Accessories…Two types of back covers (flat type, flanged type)▪️For measuring surface irregularities, workpiece mounting quality, shaft runout, perpendicularity, and other displacements.
▪️The most common dial gauge with a scale division of 0.01mm.▪️Equipped with a limit needle.▪️Uses jewel bearings in the bearing section.▪️Scale plate is green.▪️Two types of back covers included: flat type and type with lugs.▪️Shockproof mechanism protects the gears from sudden upward pressure on the spindle.
Brand Name: Esco
Scale (mm)...0.01
Measuring Force...1.5N or less
Measuring Range (mm)...0 to 10
Scale Specification...±0 to 100
Dial Diameter (mm)...58
Overall Length (mm)...112
Mounting Shaft Diameter...φ8mm
Probe Length...21mm
Material…Body: Steel Probe Tip: Carbide
Return Error…3μm
4550061775004
Esco 10mm/0.01/58mm Dial Gauge EA725MA-22
(text created at , 2025-05-10)
Package
Size (Approx.):
Size (Approx.):
- mm
Package
Weight (Approx.):
Weight (Approx.):
- g
7,587 JPY (Including Tax)
